The Orcon MVS-15RH CO2B Max Summer Night Comfort 550 m³/h is an advanced ventilation unit for demand-controlled mechanical ventilation. Equipped with built-in humidity and temperature sensors alongside external CO₂ sensors, the system automatically adjusts the ventilation requirements of the home. Thanks to the unique summer night ventilation, this unit provides additional cooling during warm nights. The unit operates quietly, is energy-efficient, and suitable for both new builds and renovations.
The Orcon MVS-15RH CO2B Max Summer Night Comfort 550 m³/h comes standard with:
These sensors collectively ensure precise, automatic control of the ventilation system. In addition to the sensors listed above, the unit itself contains a humidity and temperature sensor.
The Orcon MVS-15RH CO2B Max is ideal for homes prioritising a high comfort level and energy efficiency. Suitable for use in bathrooms, kitchens, toilets, and living areas. Thanks to its passive summer night cooling, this system is especially well suited for well-insulated homes and BENG (Nearly Energy-Neutral Buildings) applications.
The unit features five connections with a diameter of 125 mm (optional 160 mm), operates on 230 V (earthed plug), and has an IP21 rating. Maximum airflow: 550 m³/h at 100 Pa. Installation possible on wall, ceiling, or attic. Operates within an ambient temperature range from -10 °C to +40 °C. The Orcon CO₂ control sensor connects wirelessly to the unit but always requires a 230V power supply to function.
The Orcon MVS-15RH CO2B Max Summer Night Comfort offers smart, automatic ventilation with integrated sensors and night ventilation. This provides you with fresh air, reduced energy consumption, and increased comfort—even during warm summer nights. A future-proof choice for modern ventilation requirements.
| Brand | Orcon |
| Category | All mechanical ventilation systems |
| GTIN | 8720701076648 |
| Manufacturer's item number | 21140060 |
| Article number | 19130042 |
| Category code | 10 |
| Housing material | Plastic |
| Max. air volume at 50 Pa | 580 m³/h |
| Max. air volume at 100 Pa | 550 m³/h |
| Max. air volume at 150 Pa | 510 m³/h |
| Max. air volume at 200 Pa | 490 m³/h |
| Max. air volume at 250 Pa | 470 m³/h |
| Max. air volume at 300 Pa | 420 m³/h |
| Power consumption at max. air volume at 100 Pa | 80 W |
| Frequency supply voltage (min) | 50 Hz |
| Frequency supply voltage (max) | 60 Hz |
| Supply voltage (min) | 200 V |
| Supply voltage (max) | 240 V |
| Max. nominal current | 0.8 A |
| Sound power level | 46 dB(A) |
| Type of motor | Electronically commutated (EC) |
| Electrical connection | Connecting cable with plug with protective contact |
| Energy efficiency class | B |
| Control signal | PWM (pulse-width-modulated) |
| Type of speed control | 3 positions |
| Type of switch | Other |
| With wireless remote control | No |
| Suitable for wireless remote control | Yes |
| With wired control unit | No |
| Suitable for wired control unit | No |
| Suitable for requirement-controlled ventilation | Yes |
| With internal humidity (RH) sensor | Yes |
| With external humidity (RH) sensor | No |
| Suitable for (extra) humidity (RH) sensor | Yes |
| With internal carbon dioxide (CO2) sensor | No |
| With external carbon dioxide (CO2) sensor | Yes |
| Suitable for (extra) carbon dioxide (CO2) sensor | Yes |
| Detects volatile organic compounds | No |
| With pressure sensor | No |
| Suitable for (extra) pressure sensor | No |
| With constant volume flow control | No |
| With zone controller | No |
| Suitable for zone controller | No |
| Operation by app | No |
| With movement sensor | No |
| Suitable for movement sensor | No |
| Sensor controlled air flow | No |
| Number of suction connections | 5 |
| Number of kitchen connections | 1 |
| Max. number of wet zones | 5 |
| Connection | Insert end |
| Nominal duct diameter suction side | 125 mm |
| Nominal duct diameter exhaust air | 125 mm |
| Nominal duct diameter sanitary connections | 125 mm |
| Nominal duct diameter kitchen connections | 125 mm |
| Suitable for wall mounting | Yes |
| Suitable for ceiling mounting | Yes |
| Suitable for mounting in suspended ceiling | Yes |
| Suitable for mounting in an attic | Yes |
| Suitable for floor mounting | Yes |
| Suitable for suspended mounting | Yes |
| Horizontal mounting | Yes |
| Vertical mounting | Yes |
| Rear connection | Yes |
| Depth | 303 mm |
| Height | 389 mm |
| Width | 449 mm |
| Weight | 4.99 kg |
| Energy label | B |
| Plug type | Earthed plug |
