1x Orcon MVS 15RH 550m³/h with earthed plug
1x Built-in humidity sensor
4x Plastic vents with clamp springs with a diameter of 125mm
Truly a quiet fan! These ultimate performance levels are achieved through several enhancements. One of the key improvements is the new “GreenTech RadiCal” DC motor housed in an EPP scroll casing! This combination ensures exceptionally low noise operation. Additionally, the airtightness and sound-dampening effect have been greatly enhanced thanks to the EPP scroll. The MVS-15RH provides the perfect balance between noise, energy consumption, and comfort!
The humidity sensor is standard integrated in the residential ventilation unit (type RH) and measures the moisture content in the extracted air from the kitchen, bathroom, and toilet. In automatic mode, the fan operates at the lowest speed with the humidity sensor active. If the built-in humidity sensor detects rising moisture levels, for example during cooking or showering, the unit will switch to a higher speed. Fifteen minutes after cooking or showering, the fan returns to the low speed.
| Brand | Orcon |
| Category | All mechanical ventilation systems |
| GTIN | 8719544111531 |
| Manufacturer's item number | 19130015 |
| Article number | 19130015 |
| Bundle type | Ventilation box + RFT-N Auto control + 4 valves |
| Category code | 9000 |
| Housing material | Plastic |
| Max. air volume at 50 Pa | 580 m³/h |
| Max. air volume at 100 Pa | 550 m³/h |
| Max. air volume at 150 Pa | 510 m³/h |
| Max. air volume at 200 Pa | 490 m³/h |
| Max. air volume at 250 Pa | 470 m³/h |
| Max. air volume at 300 Pa | 420 m³/h |
| Power consumption at max. air volume at 100 Pa | 80 W |
| Frequency supply voltage (min) | 50 Hz |
| Frequency supply voltage (max) | 60 Hz |
| Supply voltage (min) | 200 V |
| Supply voltage (max) | 240 V |
| Max. nominal current | 0.8 A |
| Sound power level | 46 dB(A) |
| Type of motor | Electronically commutated (EC) |
| Electrical connection | Connecting cable with plug with protective contact |
| Energy efficiency class | D |
| Control signal | PWM (pulse-width-modulated) |
| Type of speed control | 3 positions |
| Type of switch | Other |
| With wireless remote control | Yes |
| Suitable for wireless remote control | Yes |
| With wired control unit | No |
| Suitable for wired control unit | No |
| Suitable for requirement-controlled ventilation | Yes |
| With internal humidity (RH) sensor | Yes |
| With external humidity (RH) sensor | No |
| Suitable for (extra) humidity (RH) sensor | Yes |
| With internal carbon dioxide (CO2) sensor | No |
| With external carbon dioxide (CO2) sensor | No |
| Suitable for (extra) carbon dioxide (CO2) sensor | Yes |
| Detects volatile organic compounds | No |
| With pressure sensor | No |
| Suitable for (extra) pressure sensor | No |
| With constant volume flow control | No |
| With zone controller | No |
| Suitable for zone controller | No |
| Operation by app | No |
| With movement sensor | No |
| Suitable for movement sensor | No |
| Sensor controlled air flow | No |
| Number of suction connections | 5 |
| Max. number of wet zones | 5 |
| Connection | Insert end |
| Nominal duct diameter suction side | 125 mm |
| Nominal duct diameter exhaust air | 125 mm |
| Nominal duct diameter sanitary connections | 125 mm |
| Nominal duct diameter kitchen connections | 125 mm |
| Suitable for wall mounting | Yes |
| Suitable for ceiling mounting | Yes |
| Suitable for mounting in suspended ceiling | Yes |
| Suitable for mounting in an attic | Yes |
| Suitable for floor mounting | Yes |
| Suitable for suspended mounting | Yes |
| Horizontal mounting | Yes |
| Rear connection | Yes |
| Depth | 303 mm |
| Height | 389 mm |
| Width | 449 mm |
| Weight | 4.77 kg |
| Energy label | D |
| Plug type | Earthed plug |
| Vertical mounting | Yes |
