Orcon MVS-15RH CO2B 550 m³/h + humidity sensor + CO2 control sensor - grounding plug 19130014

Good points

Energy efficient

Moisture & CO2 sensor

520 m³/h

C+

Orcon MVS-15RH CO2B 550 m³/h + humidity sensor + CO2 control sensor - earthed plug

Rightfully considered a 100% silent fan! These ultimate performances stem from several modifications. One of the most important changes is the new “GreenTech RadiCal” DC motor housed in an EPP scroll casing! This combination ensures extremely low noise operation. Thanks to the EPP scroll housing, both airtightness and soundproofing are significantly enhanced. The MVS-15RH CO2B with CO2 sensor strikes the perfect balance between noise level, energy consumption and comfort! Moreover, you can connect up to 20 wireless modules to this Orcon mechanical ventilation unit!

The humidity sensor is standard integrated into the domestic ventilation fan (type RH) and measures the moisture content in the extracted air from the kitchen, bathroom and toilet. In automatic mode, the fan operates at the lowest setting and the humidity sensor is active. If the built-in humidity sensor detects an increase in humidity—for example during cooking or showering—the unit switches to a higher speed. Fifteen minutes after showering or cooking, it switches back to the low speed.

Key features of the fan

One of the quietest fans across all fan speeds!

Includes 1 sensor/control unit

The Orcon CO₂ control sensor wirelessly connects to the unit but always requires a 230V power supply to operate.

Highest EPC reduction

Standard with integrated humidity sensor (RH)

Maximum airflow of 550 m³/h at 150 Pa

28 adjustable airflow settings

Bottom connection available in Ø 160 or Ø 125!

Key features of the humidity sensor

Automatic humidity-based control

Built into MVS, no additional components required

Adjustable overrun time (15 or 30 minutes)

Adjustable overrun speed (medium or high)

Blogs

See all blogs

Bundle type	Ventilation box + RFT-N Auto control
Category code	10
Housing material	Plastic
Max. air volume at 50 Pa	580 m³/h
Max. air volume at 100 Pa	550 m³/h
Max. air volume at 150 Pa	510 m³/h
Max. air volume at 200 Pa	490 m³/h
Max. air volume at 250 Pa	470 m³/h
Max. air volume at 300 Pa	420 m³/h
Power consumption at max. air volume at 100 Pa	80 W
Frequency supply voltage (min)	50 Hz
Frequency supply voltage (max)	60 Hz
Supply voltage (min)	200 V
Supply voltage (max)	240 V
Max. nominal current	0.8 A
Sound power level	46 dB(A)
Type of motor	Electronically commutated (EC)
Electrical connection	Connecting cable with plug with protective contact
Energy efficiency class	B
Control signal	PWM (pulse-width-modulated)
Type of speed control	3 positions
Type of switch	Other
With wireless remote control	No
Suitable for wireless remote control	Yes
With wired control unit	No
Suitable for wired control unit	No
Suitable for requirement-controlled ventilation	Yes
With internal humidity (RH) sensor	Yes
With external humidity (RH) sensor	No
Suitable for (extra) humidity (RH) sensor	Yes
With internal carbon dioxide (CO2) sensor	No
With external carbon dioxide (CO2) sensor	Yes
Suitable for (extra) carbon dioxide (CO2) sensor	Yes
Detects volatile organic compounds	No
With pressure sensor	No
Suitable for (extra) pressure sensor	No
With constant volume flow control	No
With zone controller	No
Suitable for zone controller	No
Operation by app	No
With movement sensor	No
Suitable for movement sensor	No
Sensor controlled air flow	No
Number of suction connections	5
Max. number of wet zones	5
Connection	Insert end
Nominal duct diameter suction side	125 mm
Nominal duct diameter exhaust air	125 mm
Nominal duct diameter sanitary connections	125 mm
Nominal duct diameter kitchen connections	125 mm
Suitable for wall mounting	Yes
Suitable for ceiling mounting	Yes
Suitable for mounting in suspended ceiling	Yes
Suitable for mounting in an attic	Yes
Suitable for floor mounting	Yes
Suitable for suspended mounting	Yes
Horizontal mounting	Yes
Vertical mounting	Yes
Rear connection	Yes
Depth	303 mm
Height	389 mm
Width	449 mm
Weight	4.78 kg
Energy label	B
Plug type	Earthed plug
