Good points
- Including digital control
- Enthalpy changer
- Central readout
- 600m³/h
Orcon heat recovery unit
Orcon's decentralised heat recovery unit is specially developed for creating an optimal indoor climate. In many offices and other spaces, the CO2 values are often too high. This can be prevented by installing a decentralised heat recovery unit. Each individual room is thus provided with healthy and fresh air and contributes to an optimal indoor climate. Orcon's MVHR units are among the smartest on the market. They have various sensors and an integrated smart controller and display.
Air regulation
The WTU- EC-E is equipped with heat recovery. Therefore, the WTU-EC-E heats the cold air from outside with the warm air from inside. In order to obtain cool air in the summer and to not heat up the room further, the unit is equipped as standard with a bypass. This option ensures that cold, filtered air is brought in from outside during the night. Besides recovering heat, the system also recovers humidity by means of an enthalpy heat exchanger. This keeps the temperature and relative humidity at a comfortable level.
What makes the WTU-EC-E series so special?
- Very high efficiency due to backward-curved blades
- Very low energy consumption
- Insulated to minimise noise pollution
- Room-by-room ventilation control for targeted airflow
- Readout and control via laptop using Corrigo E-tool or Corrigo Application Tool (free to download at https://orcon.nl/wtu-downloads/)
- Supplied with a Regin controller and digital control panel
- Controller type: Corigo Ardo 3.6 or 5.0
- MOD-bus/BAC-net/Exoline over TCP/IP and RS-485 (for full BMS integration)
Software
Orcon also offers software via their E-tool:
| Brand | Orcon |
| Category | Heat recovery choice aid |
| GTIN | 8718403862560 |
| Manufacturer's item number | 15100006 |
| Article number | 19220059 |
Specifications
| Category code | 17 |
| Device emplacement | Indoor positioning |
| Housing material | Steel, lined |
| Max. air volume at 50 Pa | 715 m³/h |
| Max. air volume at 100 Pa | 655 m³/h |
| Max. air volume at 150 Pa | 610 m³/h |
| Max. air volume at 200 Pa | 565 m³/h |
| Max. air volume at 250 Pa | 500 m³/h |
| Max. air volume at 300 Pa | 430 m³/h |
| Fan type | Direct |
| Type of motor | Electronically commutated (EC) |
| Heat recovery by | Cross-counter-flow unit |
| Type of cooling coil | None |
| Type of heating coil | None |
| Change-over system | No |
| With bypass | Yes |
| Supply filter according to ISO 16890-1:2016 | ISO Coarse |
| Efficiency supply filter according to ISO 16890-1:2016 | 45 % |
| Exhaust filter according to ISO 16890-1:2016 | ISO Coarse |
| Efficiency exhaust filter according to ISO 16890-1:2016 | 45 % |
| With condensate drain | No |
| Frost protection circuit | No |
| With constant pressure control | No |
| With constant volume flow control | No |
| Connection voltage | 1x 230 V AC |
| Electrical connection | Connection cable with plug |
| With thermal overload protection | Yes |
| Power consumption | 0.228 kW |
| Thermal efficiency | 73 % |
| Suitable for electronic control | Yes |
| Suitable for low-current control | Yes |
| With rotational speed/frequency control | Yes |
| Suitable for transformer control | No |
| Nominal duct diameter, outdoor connection | 200 mm |
| Connection | Flange |
| Length | 1130 mm |
| Width | 922 mm |
| Height | 344 mm |
| With roof plate | No |
| With support frame | No |
| Weight | 46 kg |
| With enthalpy exchanger | No |
