Good points
- 280 m³/h
- Straight applicable
- Energy label A+
- Thermal efficiency 90%
Vent Axia Lo-Carbon Sentinel Kinetic FR - right - 280 m³/h
The Lo-Carbon Sentinel Kinetic F from Vent-Axia is a MVHR unit with plastic counterflow heat exchanger which achieves a thermal efficiency of up to 90%. The Kinetic-F can ventilate 280m³/h at 150Pa. Due to its relatively compact size, this MVHR unit is easy to mount under the roof or in a cabinet. In addition, the ducts can be connected both horizontally and vertically or combined to the Sentinel Kinetic F. The condensate drain can be installed on the back, side or bottom of the unit and can also be connected after installation.
Demand-controlled ventilation
Thanks to the integrated humidity sensor, the Vent-Axia Lo-Carbon Sentinel Kinetic F provides extra ventilation when moisture is detected. In addition, when the relative humidity has decreased, the MVHR unit will automatically slow down, saving energy and not producing unnecessary noise. The night setting allows the unit to avoid unnecessarily ventilating at high speed when the humidity increases due to a drop in temperature.
Right-hand version
The Sentinel Kinetic FR has the connections to and from the right side. The MVHR unit is also available in a left-hand version.
Vent-Axia Lo-Carbon Sentinel Kinetic F advantages
- Plastic counterflow heat exchanger
- Thermal efficiency up to 90%
- Automatic summer bypass
- Very quiet
- Light weight
- Simple installation
- Horizontal and vertical duct connection possible
- Plug-and-play: automatic sensor detection
- Connectable to building management system
- Adjustable timer for start delay and delayed switch-off time
| Brand | Vent-Axia |
| Category | All MVHR units |
| GTIN | 5015135081676 |
| Manufacturer's item number | 8000000052 |
| Article number | 19500052 |
Specifications
| Category code | 73 |
| Heat recovery by | Cross-counter-flow unit |
| Housing material | Plastic |
| Housing material quality | Other |
| Material heat exchanger | Plastic |
| Suitable for wall mounting | Yes |
| Suitable for ceiling mounting | No |
| Suitable for floor mounting | No |
| Left/right orientation reversible | No |
| Max. air volume at 150 Pa | 320 m³/h |
| Type of motor | Electronically commutated (EC) |
| Voltage | 230 V |
| Frequency | 50 Hz |
| Number of phases | 1 |
| Electrical connection | Terminals |
| Energy efficiency class according to 1253/2014/EU | A+ |
| With digital display | Yes |
| With wired control unit | No |
| Suitable for wired control unit | Yes |
| Suitable for wireless remote control | No |
| Supporting protocol for Modbus | No |
| With zone controller | No |
| Suitable for zone controller | Yes |
| With volatile organic compound (VOC) sensor | No |
| Suitable for extra VOC sensor | Yes |
| With internal humidity (RH) sensor | Yes |
| Suitable for (extra) humidity (RH) sensor | Yes |
| With internal carbon dioxide (CO2) sensor | No |
| Suitable for (extra) carbon dioxide (CO2) sensor | Yes |
| Suitable for central heating boiler connection | No |
| With bypass | Yes |
| With constant pressure control | No |
| With constant volume flow control | No |
| Nominal duct diameter (min) | 180 mm |
| Nominal duct diameter (max) | 180 mm |
| Residential connection, underside | No |
| Residential connection, left side | Yes |
| Residential connection, right side | No |
| Residential connection, top | Yes |
| Roof connection, side | Yes |
| Roof connection, top | Yes |
| Height | 550 mm |
| Width | 555 mm |
| Depth | 350 mm |
| Degree of protection (IP) | IP22 |
| Weight | 18 kg |
| Energy label | A+ |
| Connection type | connection right |
| With enthalpy exchanger | No |
| Plug type | Euro plug |
