Good points
- 390 m³/h
- Left applicable
- Energy label A+
- Thermal efficiency 92%
Vent - Axia Lo-Carbon Sentinel Kinetic Plus - left - 390 m³/h
The Lo-Carbon Sentinel Kinetic Plus from Vent-Axia is a high-quality MVHR unit. With the plastic counterflow heat exchanger, the unit can achieve a thermal efficiency of up to 92%. The Kinetic Plus can ventilate 390m³/h at 150Pa. Thanks to the highly efficient fans with rearward-curved vanes, the MVHR unit is very economical and quiet. Due to the high air flow rate, the unit is extremely suitable for both small houses and large buildings.
Demand-controlled ventilation
Due to the integrated humidity sensor, the Kinetic Plus has additional ventilation when moisture is detected. In addition, when the relative humidity has decreased, the MVHR unit will automatically slow down, saving energy and not producing unnecessary noise. The night setting allows the unit to avoid unnecessarily ventilating at high speed when the humidity increases due to a drop in temperature.
Connections
The connections to the air ducts are variable. The spouts can be placed both horizontally and vertically or combined on the Kinetic Plus.
Left-hand version
The Sentinel Kinetic B Plus L has the connections to and from the left side. The MVHR unit is also available in a right-hand version.
Advantages of the Vent-Axia Lo-Carbon Sentinel Kinetic Plus:
- Automatic summer by-pass and freeze protection
- Low sound level
- Horizontal and vertical connection of ducts possible
- Plug-and-play simple installation
- Light weight
- Connectable to building management system
- Adjustable timer and delayed switch-off time
| Brand | Vent-Axia |
| Category | All MVHR units |
| GTIN | 5015135062194 |
| Manufacturer's item number | 8000000057 |
| Article number | 19500057 |
Specifications
| Category code | 73 |
| Width | 775 mm |
| Height | 630 mm |
| Depth | 524 mm |
| Nominal duct diameter (min) | 180 mm |
| Nominal duct diameter (max) | 180 mm |
| Housing material | Plastic |
| Heat recovery by | Cross-counter-flow unit |
| Suitable for ceiling mounting | No |
| Suitable for wall mounting | Yes |
| Material heat exchanger | Plastic |
| Housing material quality | Other |
| Suitable for floor mounting | No |
| Left/right orientation reversible | No |
| Electrical connection | Terminals |
| Type of motor | Electronically commutated (EC) |
| With zone controller | No |
| Frequency | 50 Hz |
| With wired control unit | No |
| Supporting protocol for Modbus | No |
| Suitable for central heating boiler connection | No |
| With constant pressure control | No |
| Roof connection, top | Yes |
| Residential connection, top | Yes |
| With internal humidity (RH) sensor | No |
| Suitable for extra VOC sensor | Yes |
| Degree of protection (IP) | IP22 |
| Residential connection, left side | No |
| Max. air volume at 150 Pa | 390 m³/h |
| Voltage | 230 V |
| With digital display | Yes |
| Suitable for wired control unit | Yes |
| Number of phases | 1 |
| Energy efficiency class according to 1253/2014/EU | A+ |
| With volatile organic compound (VOC) sensor | No |
| Suitable for zone controller | Yes |
| Suitable for wireless remote control | No |
| With constant volume flow control | No |
| With bypass | Yes |
| Residential connection, right side | Yes |
| With internal carbon dioxide (CO2) sensor | No |
| Roof connection, side | Yes |
| Residential connection, underside | No |
| Weight | 24 kg |
| Suitable for (extra) humidity (RH) sensor | Yes |
| Suitable for (extra) carbon dioxide (CO2) sensor | Yes |
| Plug type | Euro plug |
| Energy label | A+ |
| Connection type | connections links |
| With enthalpy exchanger | No |
