Good points
- 220 m³/h
- Energy label A
- 100% bypass
- Thermal efficiency 92%
Vent-Axia Lo-Carbon Sentinel Kinetic - 220 m³/h
The Lo-Carbon Sentinel Kinetic from Vent-Axia is a high-quality MVHR unit. With the plastic counterflow heat exchanger, the unit can achieve a thermal efficiency of up to 92%. The Kinetic can ventilate 220 m³/h at 150 Pa. Due to its compact size, the MVHR unit can easily be mounted in a kitchen or cabinet (at least 290mm deep). Unique to the Lo-Carbon Sentinel Kinetic is that it is suitable for installation on both the left and right. The unit is supplied with the connection to the outside on the right side by default. This can be easily reversed by placing the control of the Sentinel Kinetic on the other side of the unit. The condensate drain can be installed on the back, side or bottom of the unit and can also be connected after installation.
As the connections can be established both horizontally and vertically or combined, the heat recovery unit can be mounted in confined spaces. With additional spouts, both horizontal and vertical connection at the same position is possible.
Vent-Axia Lo-Carbon Sentinel Kinetic advantages:
- Plastic counterflow plate exchanger
- Effiency of up to 92%
- Integrated digital control
- Automatic silent
- Light in weight
- Simple installation
- Horizontal and vertical connection of ducts possible
- Connectable to building management system
| Brand | Vent-Axia |
| Category | All MVHR units |
| GTIN | 5015135382223 |
| Manufacturer's item number | 8000000046 |
| Article number | 19500046 |
Specifications
| Category code | 73 |
| Width | 550 mm |
| Height | 550 mm |
| Depth | 285 mm |
| Nominal duct diameter (min) | 125 mm |
| Nominal duct diameter (max) | 125 mm |
| Housing material | Plastic |
| Heat recovery by | Cross-counter-flow unit |
| Suitable for ceiling mounting | No |
| Suitable for wall mounting | Yes |
| Material heat exchanger | Plastic |
| Housing material quality | Other |
| Suitable for floor mounting | No |
| Left/right orientation reversible | No |
| Electrical connection | Connecting cable with plug with protective contact |
| Type of motor | Electronically commutated (EC) |
| Frequency | 50 Hz |
| With wired control unit | No |
| Supporting protocol for Modbus | No |
| Suitable for central heating boiler connection | No |
| Roof connection, top | Yes |
| Residential connection, top | Yes |
| With internal humidity (RH) sensor | No |
| Suitable for extra VOC sensor | Yes |
| Degree of protection (IP) | IP22 |
| Residential connection, left side | Yes |
| Max. air volume at 150 Pa | 220 m³/h |
| Voltage | 230 V |
| With digital display | Yes |
| Suitable for wired control unit | Yes |
| Number of phases | 1 |
| Energy efficiency class according to 1253/2014/EU | A |
| With volatile organic compound (VOC) sensor | No |
| Suitable for zone controller | Yes |
| Suitable for wireless remote control | No |
| With bypass | Yes |
| Residential connection, right side | No |
| Roof connection, side | Yes |
| Residential connection, underside | No |
| Weight | 15 kg |
| Suitable for (extra) humidity (RH) sensor | Yes |
| Suitable for (extra) carbon dioxide (CO2) sensor | Yes |
| With thermal overload protection | Yes |
| Plug type | Euro plug |
| Energy label | A |
| Connection type | connections links |
| With enthalpy exchanger | No |
