Good points

Thermal efficiency up to 91.7%
Energy label A+
Automatic cooling with outside air
Ceiling, wall or floor mounting

Orcon WTW HRC-360-OptiAir-Eco

The Orcon HRC-360 OptiAir Eco is a balanced ventilation system with heat recovery designed for larger homes and apartments with higher ventilation demands. The system operates based on demand control, recovering heat from the exhausted indoor air to preheat the fresh incoming air. With a maximum capacity of 360 m³/h and a thermal efficiency of 89.5%, this unit is the more powerful variant within the OptiAir Eco range. Like the 260 model, the Eco version uses imbalance as frost protection, eliminating the need for a separate preheater.

Advantages and Features

360 m³/h capacity for larger homes: the HRC-360 OptiAir Eco ventilates spaces with higher air flow requirements, such as larger family homes or multi-storey dwellings.
Thermal efficiency of 89.5% and energy label A (A+ with additional sensor): the system recovers nearly all the heat from the extracted air and transfers it to the incoming fresh air, substantially reducing heating energy demand.
Modulating 100% bypass for passive cooling: during warm summer nights, the bypass fully opens to allow cool outside air to enter the home directly, bypassing the heat exchanger.
Constant volume control with 1% accuracy: airflow remains stable regardless of duct resistance, ensuring each room receives the correct amount of air.
Three installation options in one compact unit: the unit (1070 x 830 x 320 mm, 23 kg) is suitable for ceiling, wall, or floor mounting, making it adaptable to diverse building situations.
Expandable with wireless RF control: connect CO2 sensors, humidity sensors or an HRC Display wirelessly to the unit to enable room-specific demand control and achieve energy label A+.

Powerful Ventilation with Low Energy Consumption

At a maximum capacity of 360 m³/h, the HRC-360 OptiAir Eco consumes 85 W. The ePM1 70% filter class on the supply side screens fine dust from outdoor air, contributing to a healthier indoor climate. Thanks to its demand-controlled operation, the system runs mostly at lower speeds, reducing both energy consumption and noise levels compared to a system running at full load continuously.

Installation, Maintenance and Applications

The HRC-360 OptiAir Eco is suitable for new build properties and renovation projects requiring high ventilation capacity. The duct connections are 4 x 180 mm, compatible with larger duct diameters typically used in spacious homes. The unit comes with a mains cable fitted with grounding. Ceiling mounting is the default configuration, and using separate wall or floor mounting kits increases installation flexibility. All filters and maintenance-sensitive components can be accessed without dismantling the unit or removing it from the ceiling. Airflow per ventilation position is adjustable via dipswitches on the control board.

Brand	Orcon
Category	All MVHR units
GTIN	8720701078369
Manufacturer's item number	22020300
Article number	19130028

Specifications

Category code	218
Housing material	Plastic
Housing material quality	Expanded polypropylene (EPP)
Material heat exchanger	Plastic
Suitable for wall mounting	Yes
Suitable for ceiling mounting	Yes
Suitable for floor mounting	Yes
Suitable for mounting in suspended ceiling	Yes
Suitable for mounting in an attic	Yes
Orientation	Left/right (reversible)
Max. air volume at 50 Pa	360 m³/h
Max. air volume at 100 Pa	360 m³/h
Max. air volume at 150 Pa	360 m³/h
Max. air volume at 200 Pa	360 m³/h
Max. air volume at 250 Pa	360 m³/h
Max. air volume at 300 Pa	360 m³/h
Sound power level according to 1254/2014/EU	50 dB(A)
Power consumption at max. air volume at 100 Pa	108 W
Thermal efficiency at 70% air volume at 50 Pa	89.5 %
Type of motor	Electronically commutated (EC)
Voltage	230 V
Frequency	50 Hz
Number of phases	1
Fuse size of the device	6 A
With thermal overload protection	No
Electrical connection	Connecting cable with plug with protective contact
Energy efficiency class according to 1253/2014/EU	A
Type of switch	Other
With digital display	No
With wired control unit	No
Suitable for wired control unit	No
With wireless remote control	No
Suitable for wireless remote control	Yes
Supporting protocol for Modbus	Yes
Operation by app	No
With zone controller	No
Suitable for zone controller	Yes
With heating element	No
With volatile organic compound (VOC) sensor	No
Suitable for extra VOC sensor	No
With external humidity (RH) sensor	No
With internal humidity (RH) sensor	Yes
Suitable for (extra) humidity (RH) sensor	Yes
With internal carbon dioxide (CO2) sensor	No
Suitable for (extra) carbon dioxide (CO2) sensor	Yes
Suitable for central heating boiler connection	No
With bypass	Yes
With constant pressure control	No
With constant volume flow control	Yes
Type of frost protection	Other
Nominal duct diameter (min)	180 mm
Nominal duct diameter (max)	180 mm
Number of outdoor air connections (ODA) according to EN 13141-7	1
Number of supply air connections (SUP) according to EN 13141-7	1
Number of extract air connections (ETA) according to EN 13141-7	1
Number of exhaust air connections (EHA) according to EN 13141-7	1
Connections outdoor air (ODA)	Insert end
Connections supply air (SUP)	Insert end
Connections extract air (ETA)	Insert end
Connections exhaust air (EHA)	Insert end
Supply filter according to ISO 16890-1:2016	ISO ePM1
Efficiency supply filter according to ISO 16890-1:2016	70 %
Exhaust filter according to ISO 16890-1:2016	ISO Coarse
Efficiency exhaust filter according to ISO 16890-1:2016	65 %
Height	830 mm
Width	1080 mm
Depth	324 mm
Degree of protection (IP)	IP30
Weight	23.88 kg
Heat recovery by	Cross-counter-flow unit
