Galvanised flat duct 300x80 lengte 1.5m

Brand: Econox


Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
Galvanised flat duct 300x80 lengte 1.5m
61.69
    • 100 units expected on 23-07-2024
  • Customer review 9/10
  • In stock? Delivery within 3 working days
  • Free shipping from 100,-
  • Safe shopping with Trustedshops

Pay safe and fast with:

  • MasterCard
  • VISA
  • American Express
  • Maestro / Postepay
  • PayPal
  • Bank transfer

Good points

  • Galvanised
  • Length 1500 mm

Galvanised flat duct 300x80 lengte 1.5m

The galvanised flat ventilation duct or galvanised flat duct with 300mm x 80mm size is suitable for various applications. For example, the flat ventilation duct can be used as a surface-mounted ventilation duct to extract air through the extractor hood. The flat exhaust pipe can also be used for the supply and extraction of air through another ventilation system if desired.
In addition, the galvanised flat duct can be used for embedding in concrete or other mortar, in a wall, floor or ceiling. Combined with an galvanised flat duct and various fittings, a ventilation duct can be installed as desired by using a flat exhaust pipe.

The high-quality galvanised steel guarantees a long service life and prevents corrosion of the flat duct. In order to protect the channel from damage, you should lay reinforcement over the channel.

Available in various sizes
Size 300 mm x 80 mm
Length: 1.5 m

Brand Econox
Category Galvanised flat ducts and fittings 300x80
GTIN 8719544145994
Manufacturer's item number 30080015
Article number 30080015

Specifications

Width 300 mm
Pressure loss at 3m/s 1.1 Pa/m
Pressure loss at 5m/s 2.6 Pa/m
Height 80 mm
Length 1500 mm
Material thickness 0.6 mm
Displaced air at 3m/s 259 m³/h
Displaced air at 5m/s 432 m³/h
Category code 26
