Brink Renovent Sky 150 - Brink Air Control Module included
Due to problems with the supply of raw materials, there is currently a long delivery time on Brink MVHR units. Ordering is possible, but we cannot give a definite delivery date. We do have sufficient stock of alternative brands such as Orcon, Vasco, Duco, Vent-Axia, BUVA, Itho and Comair.
Optimal and compact heat recovery with the Renovent Sky 150 from Brink Climate Systems. This unit is special in its kind because it is only 20 cm high and at the same time extremely low-noise. The Brink Renovent Sky 150 owes this to the fact that it is equipped with a reduced internal resistance and slow-running fans.
Just like its big brothers in the Renovent Excellent series, the Brink Renovent Sky 150 optimises the indoor climate, so that pathogens caused by polluted air no longer stand a chance. In addition, this balanced ventilation is also energy-saving due to its high heat recovery efficiency.
Compact but powerful Brink Renovent Sky 150
The Brink Renovent Sky 150 is therefore extremely suitable for smaller living spaces such as student flats and homes for the elderly where it is not possible to install a wall unit due to the lack of space. Nevertheless, this compact system has an air capacity of 150m3/h.
Brand | Brink Climate Systems |
Category | Brink Renovent sky 150 |
GTIN | 8718391148554 |
Manufacturer's item number | 423000 |
Article number | 19210063 |
Specifications
Connection diameter | 125 mm |
Connection | Male |
Connection 0-10V | No |
Airflow bij 150 Pa | 150 m³/h |
Airflow at 200 Pa | 120 m³/h |
App controllable | No |
Breedte | 660 mm |
Cos. phi according to EPN standard | 0,46 |
Roof connection top | No |
Roof connection side | Yes |
Depth | 1000 mm |
Digital display | Yes |
Home automation connection | No |
Wireless control | Yes |
Enthalpy changer | No |
Filter class | EU 4 (G4) |
Direct current motor | Yes |
Suitable for boiler connection | No |
Height | 198 mm |
Flow rate high at 100 Pa | 150 m³/h |
Flow rate high at 150 Pa | 150 m³/h |
Flow rate high at 200 Pa | 120 m³/h |
Flow rate high at 250 Pa | 90 m³/h |
Flow rate high at 300 Pa | 60 m³/h |
Maandactie | No |
Housing material | Steel coated |
With VOC-sensor | No |
With bypass | Yes |
With built-in CO2-sensor | No |
With built-in temperature sensor | Yes |
With thermal protection | Yes |
With heating battery | Yes |
With humidity sensor | No |
Mounting for | Wall |
Mounting for | Ceiling |
Power consumption according to EPN standard | 0.028 |
Ceiling mounting | Yes |
Thermal efficiency according to EPN standard | 89.3 % |
Plug | Peripheral ground |
Floor mounting | No |
Wall mounting | Yes |
House connection top | No |
House connection bottom | No |
House connection left | Yes |
House connection right | Yes |
Zone control | 1 Zone |
