Zehnder ComfoFan Silent Move Up - Grounded Plug 19120507

Good points

Integrated moisture sensor
RF-compatible
Extra quiet

Zehnder Comfofan Silent Residential Ventilator Available Online at Great Prices at Ventilatieland

The updated Zehnder Comfofan fan comes in various sizes and is suitable for ventilating your home or office. The Comfofan Silent has a capacity of up to 425 m³/h. The smaller variant, the Comfofan Silent Limited, has a capacity of up to 300 m³/h. Equipped with a special motor-wing combination, the Zehnder residential ventilator is an excellent choice for mechanical ventilation air extraction. The mechanical ventilation can be easily connected to a suitable ventilation duct.

Energy-efficient and extremely quiet, the Zehnder fan also meets the highest quality standards for even more comfortable ventilation in any living space. The fan is manufactured using durable materials and comes standard with an integrated humidity sensor and an RF receiver.

The Best Residential Ventilator with the Best Guarantee

We are confident that the Comfofan Silent delivers outstanding performance and therefore offer you a 7-year warranty! Efficient ventilation starts with Zehnder mechanical ventilation!

Features of the Zehnder ComfoFan Silent that benefit you as a user:

Fully recyclable plastic housing
Energy-efficient DC motor
Adjustable in 3 speeds, 9 set points
4 connection points for air extraction
Integrated humidity sensor
Equipped with RF receiver for remote control
Low maintenance
Motor with thermal protection
Easy installation
Integrated cord storage
High capacity
Modern design

Note: The Silent Move Up is only compatible with the housings of the CMF, CMFe, and ComfoFan S series.

Brand	Zehnder Stork
Category	All mechanical ventilation systems
GTIN	8717573037280
Manufacturer's item number	458016606
Article number	19120507

Specifications

Category code	14
Housing material	Plastic
Max. air volume at 50 Pa	500 m³/h
Max. air volume at 100 Pa	475 m³/h
Max. air volume at 150 Pa	460 m³/h
Max. air volume at 200 Pa	425 m³/h
Max. air volume at 250 Pa	400 m³/h
Max. air volume at 300 Pa	350 m³/h
Frequency supply voltage (min)	50 Hz
Frequency supply voltage (max)	50 Hz
Supply voltage (min)	230 V
Supply voltage (max)	230 V
Max. nominal current	0.46 A
Type of motor	Electronically commutated (EC)
Electrical connection	Connecting cable with plug with protective contact
Energy efficiency class	B
Control signal	0 - 10 V
Type of speed control	3 positions
With wireless remote control	No
Suitable for wireless remote control	Yes
With wired control unit	No
Suitable for wired control unit	Yes
Suitable for requirement-controlled ventilation	Yes
With internal humidity (RH) sensor	Yes
With external humidity (RH) sensor	No
Suitable for (extra) humidity (RH) sensor	Yes
With internal carbon dioxide (CO2) sensor	No
With external carbon dioxide (CO2) sensor	No
Suitable for (extra) carbon dioxide (CO2) sensor	Yes
Detects volatile organic compounds	No
With pressure sensor	No
Suitable for (extra) pressure sensor	No
With zone controller	No
Suitable for zone controller	Yes
Operation by app	No
With movement sensor	No
Suitable for movement sensor	No
Sensor controlled air flow	No
Number of suction connections	4
Connection	Insert end
Suitable for wall mounting	Yes
Suitable for ceiling mounting	Yes
Suitable for suspended mounting	No
Horizontal mounting	Yes
Vertical mounting	Yes
Rear connection	No
Depth	386 mm
Height	281 mm
Width	386 mm
Energy label	B
Plug type	Earthed plug
