Good points

Up to 91.5% thermal efficiency
Control via display and app
100% summer/night bypass
Internal moisture sensor included

Vent-Axia WTW Wall Unit Econiq 400L Left

The Vent-Axia Econiq 400 L is a heat recovery unit with a capacity of 400 m³/h, specifically designed for left-hand installation. With a maximum airflow of 460 m³/h and a thermal efficiency of 91.5%, this unit delivers excellent performance in ventilation and energy efficiency. The Econiq series represents advanced ventilation technology focused on comfort and energy saving. These units are ideal for extracting polluted and humid air from bathrooms, kitchens, and other damp areas.

Benefits of the Vent-Axia Econiq 400L:

Extensive control display: Easy operation thanks to the intuitive display.
WiFi and Bluetooth connectivity: Convenient control of the unit via the Vent-Axia Connect App.
100% summer/night bypass: Optimal comfort control with direct supply of cool outdoor air.
Compatible with RF controls: Provides additional flexibility in ventilation management.
Internal humidity sensor: Automatically regulates humidity for a healthy indoor climate.
Electric preheater: Ensures a consistent, comfortable temperature of the incoming air.
Flexible connection options: Can be connected via top and/or side inlets, simplifying installation.
Available on MEPcontent: Directly accessible for digital design integration.

Efficiency and Comfort

The Econiq units are equipped with energy-efficient DC motors, resulting in significantly reduced energy consumption without compromising performance. With an A+ energy rating and a power consumption of just 0.125 W at 100 Pa, the Econiq 400 ranks among the most efficient ventilation solutions in its class. By combining innovative technology with user-friendliness and flexibility, Vent-Axia offers a reliable solution for optimal indoor air quality in residential properties.

User-Friendly Operation

The Vent-Axia Econiq WTW units are designed with ease of use in mind. Setting up and controlling the unit is quick and straightforward. This can be done via the unit’s built-in display or through the convenient Vent-Axia Connect App. The app connects to the WTW unit via Bluetooth or WiFi, allowing desired settings to be adjusted and home ventilation managed in just a few steps. Whether it is regulating the ventilation speed, setting timers, or monitoring status information.

Bypass Function

The Vent-Axia Econiq units feature an advanced 100% summer/night bypass function, ensuring optimal comfort throughout the year. This intelligent function enables the unit to switch to bypass mode during warm summer days or nights when outdoor temperatures are cooler. Heat recovery is then disabled, and cool outdoor air is supplied directly. This provides refreshing, natural ventilation while maintaining a comfortable indoor climate without unnecessary energy use. The 100% summer/night bypass function of the Vent-Axia Econiq guarantees efficient and comfortable ventilation.

ISDE Subsidy

There is a subsidy available for the purchase of a heat pump under the Investment Subsidy for Sustainable Energy (ISDE). For more information on eligible products, general conditions, subsidy amounts, and the correct registration code, please refer to the Ventilation Units Registration Code List from RVO.

Brand	Vent-Axia
Category	All MVHR units
GTIN	5015135123987
Manufacturer's item number	8000001586
Article number	19500562

Specifications

Category code	73
Housing material	Plastic
Housing material quality	Other
Material heat exchanger	Plastic
Suitable for wall mounting	Yes
Suitable for ceiling mounting	No
Suitable for floor mounting	Yes
Suitable for mounting in suspended ceiling	No
Suitable for mounting in an attic	Yes
Max. air volume at 50 Pa	460 m³/h
Max. air volume at 100 Pa	430 m³/h
Max. air volume at 150 Pa	400 m³/h
Max. air volume at 200 Pa	360 m³/h
Max. air volume at 250 Pa	325 m³/h
Max. air volume at 300 Pa	280 m³/h
Max. volume flow according to 1254/2014/EU	400 m³/h
Sound power level according to 1254/2014/EU	47 dB(A)
Power consumption at max. air volume at 100 Pa	0.125 W
Thermal efficiency at 70% air volume at 50 Pa	91.5 %
Type of motor	Electronically commutated (EC)
Voltage	230 V
Frequency	50 Hz
Number of phases	1
Fuse size of the device	13 A
Power electric heating element (min)	2600 W
Power electric heating element (max)	2600 W
With thermal overload protection	Yes
Electrical connection	Connecting cable with plug with protective contact
Energy efficiency class according to 1253/2014/EU	A+
With digital display	Yes
With wired control unit	No
Suitable for wired control unit	Yes
Suitable for wireless remote control	Yes
Supporting protocol for Modbus	Yes
Operation by app	Yes
With zone controller	No
Suitable for zone controller	Yes
With heating element	Yes
With volatile organic compound (VOC) sensor	No
Suitable for extra VOC sensor	Yes
With external humidity (RH) sensor	No
With internal humidity (RH) sensor	Yes
Suitable for (extra) humidity (RH) sensor	Yes
With internal carbon dioxide (CO2) sensor	No
Suitable for (extra) carbon dioxide (CO2) sensor	Yes
Suitable for central heating boiler connection	No
With bypass	Yes
With constant pressure control	No
With constant volume flow control	No
Type of frost protection	Heating element
Nominal duct diameter (min)	200 mm
Nominal duct diameter (max)	200 mm
Supply filter according to ISO 16890-1:2016	ISO Coarse
Efficiency supply filter according to ISO 16890-1:2016	65 %
Exhaust filter according to ISO 16890-1:2016	ISO Coarse
Efficiency exhaust filter according to ISO 16890-1:2016	65 %
Height	931 mm
Width	728 mm
Depth	607 mm
Degree of protection (IP)	Other
Weight	48 kg
Heat recovery by	Cross-counter-flow unit
