Good points

Brand: Vent-Axia
Max 415 m3/h
92.3% thermal efficiency
Right unit

Vent-Axia WTW wall unit Econiq 350R right

The Vent-Axia Econiq series represents advanced ventilation technology with a focus on comfort and energy efficiency. These WTW (Heat Recovery) units are designed to continuously exhaust polluted and humid air from rooms such as bathrooms, kitchens, and storerooms. The removed heat is efficiently recovered and reused, resulting in a comfortable indoor environment and significant energy savings.

Advantages of the Vent-Axia Econiq 350 R:

Comprehensive control display:Easy operation thanks to the intuitive display.
Wifi and Bluetooth connectivity:Easily control the unit via the Vent-Axia Connect App.
100% summer/night bypass: Optimal comfort control with direct supply of cool outdoor air.
Suitable for RF control: Provides additional flexibility in ventilation management.
Internal humidity sensor: Automatically regulates humidity for a healthy indoor climate.
Electric preheater: Ensures a constant, comfortable temperature of incoming air.
Flexible connection options: Connectable via top and/or side connections, offering ease of installation.
Available on MEPcontent: Directly available for digital installation designs.

Efficiency and Comfort

The Econiq units are equipped with energy-efficient DC motors, resulting in significantly lower energy consumption without compromising on performance. This makes the Econiq series one of the most efficient ventilation solutions in its class. By combining innovative technologies with user-friendliness and flexibility, Vent-Axia offers a reliable solution for optimal air quality in homes.

User-friendly control

The Vent-Axia Econiq WTW units are designed with ease of use in mind. Setting up and operating the unit is quick and easy. This can be done through a display on the unit or through the handy Vent-Axia Connect App. This App connects to the WTW unit via Bluetooth or Wifi. In just a few steps, the desired settings can be adjusted and ventilation in the home can be managed. Whether it is regulating the ventilation rate, setting timers, or checking status information.

Bypass function

The Vent-Axia Econiq units feature an advanced 100% summer/night bypass function, ensuring optimal comfort all year round. This smart feature allows the unit to switch to bypass mode during hot summer days or at night when the outside temperature is cooler. This turns off the heat recovery and brings cool outside air directly into the building. This provides refreshing and natural ventilation, keeping the indoor climate pleasant without unnecessary energy consumption. With the 100% summer/night bypass function of Vent-Axia Econiq, efficient and comfortable ventilation is guaranteed.

Brand	Vent-Axia
Category	All MVHR units
GTIN	05015135996611
Manufacturer's item number	8000001417
Article number	19500551

Specifications

Category code	73
Heat recovery by	Cross-counter-flow unit
Housing material	Plastic
Housing material quality	Other
Material heat exchanger	Plastic
Suitable for wall mounting	Yes
Suitable for ceiling mounting	No
Suitable for floor mounting	Yes
Left/right orientation reversible	No
Max. air volume at 50 Pa	415 m³/h
Max. air volume at 100 Pa	380 m³/h
Max. air volume at 150 Pa	350 m³/h
Max. air volume at 200 Pa	300 m³/h
Max. air volume at 250 Pa	250 m³/h
Max. air volume at 300 Pa	200 m³/h
Max. volume flow according to 1254/2014/EU	350 m³/h
Sound power level according to 1254/2014/EU	47 dB(A)
Power consumption at max. air volume at 100 Pa	0.097 W
Thermal efficiency at 70% air volume at 50 Pa	92.3 %
Type of motor	Electronically commutated (EC)
Voltage	230 V
Frequency	50 Hz
Number of phases	1
Fuse size of the device	13 A
Power electric heating element (min)	2600 W
Power electric heating element (max)	2600 W
With thermal overload protection	Yes
Electrical connection	Connecting cable with plug with protective contact
Energy efficiency class according to 1253/2014/EU	A+
With digital display	Yes
With wired control unit	No
Suitable for wired control unit	Yes
Suitable for wireless remote control	Yes
Supporting protocol for Modbus	Yes
Operation by app	Yes
With zone controller	No
Suitable for zone controller	Yes
With heating element	Yes
With volatile organic compound (VOC) sensor	No
Suitable for extra VOC sensor	Yes
With internal humidity (RH) sensor	Yes
Suitable for (extra) humidity (RH) sensor	Yes
With internal carbon dioxide (CO2) sensor	No
Suitable for (extra) carbon dioxide (CO2) sensor	Yes
Suitable for central heating boiler connection	No
With bypass	Yes
With constant pressure control	No
With constant volume flow control	No
Type of frost protection	Heating element
Nominal duct diameter (min)	160 mm
Nominal duct diameter (max)	160 mm
Connections outdoor air side	Insert end
Connections residential side	Insert end
Residential connection, underside	No
Residential connection, left side	Yes
Residential connection, right side	No
Residential connection, top	Yes
Roof connection, side	Yes
Roof connection, top	Yes
Supply filter according to ISO 16890-1:2016	ISO Coarse
Efficiency supply filter according to ISO 16890-1:2016	65 %
Exhaust filter according to ISO 16890-1:2016	ISO Coarse
Efficiency exhaust filter according to ISO 16890-1:2016	65 %
Height	931 mm
Width	728 mm
Depth	607 mm
Degree of protection (IP)	Other
Weight	48 kg
Energy label	A+
Connection type	connection right
With enthalpy exchanger	No
Plug type	Euro plug
