Good points
- Brand: Ruck
- EC motor
- Up to 1590 m3/h
- Speed controllable
Insulated Energy-Efficient Duct Fan 280 mm – EM DUO 280 EC K 01
The Ruck EM DUO 280 EC K 01 is a quiet, powerful, and energy-efficient duct fan with sound-insulated housing. This fan is equipped with an efficient diagonal impeller and offers redundant operation for applications where reliable and continuous air displacement is essential. Thanks to the advanced CFD-optimized aerodynamics and the integrated ETAMASTER system, maximum efficiency is achieved with minimal energy consumption.
Powerful and Quiet
The EM DUO 280 EC K 01 features a continuously adjustable EC motor that is placed outside the airflow, ensuring a longer lifespan and better performance under heavy conditions. The housing is made of galvanized sheet steel and is fully insulated, providing quiet operation even at high speeds. This fan is designed for outdoor installation and is suitable for medium temperatures up to 120 °C in continuous use.
Experience the High Quality of Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of high-quality ventilation systems. With over 25 years of experience and a team of more than 300 employees, Ruck develops innovative and sustainable solutions that meet the strictest ERP requirements. The EM DUO 280 EC K 01 has also been developed according to these standards and guarantees reliable, quiet, and energy-efficient operation.
Features and Specifications
- Efficient diagonal fan with redundant operation
- Optimized aerodynamics via CFD simulation
- Sound-insulated housing made of galvanized sheet steel
- Built-in ETAMASTER for maximum efficiency
- Continuously adjustable EC motor outside the airflow
- Suitable for outdoor installation and temperatures up to 120°C
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Ruck EM DUO dubbele buisventilatoren geïsoleerd |
| GTIN | 4061199044325 |
| Manufacturer's item number | EM DUO 280 EC K 01 |
| Article number | 65172179 |
Specifications
| Category code | 35 |
| Length | 957 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 230 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 1590 m³/h |
| Suitable for frequency control | No |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 50 °C |
| Suitable for low-current control | Yes |
| Direct-current motor | Yes |
| 2-speed motor | No |
| Duct diameter | 280 mm |
