Good points
- Brand: Ruck
- EC motor
- Up to 1530 m3/h
- Speed controllable
Insulated Energy-Efficient Duct Fan 250 mm – EM DUO 250 EC K 02
The Ruck EM DUO 250 EC K 02 is a powerful and efficient duct fan with sound-insulated housing, developed for applications where reliability and noise reduction are of utmost importance. Thanks to the dual diagonal impeller, redundant operation is possible, providing extra assurance for continuous use. The aerodynamics of this fan have been optimized using CFD simulations and is equipped with a built-in ETAMASTER for maximum efficiency and pressure build-up at low energy consumption.
Powerful and Quiet
The EM DUO 250 EC K 02 features a continuously adjustable EC motor that is placed outside the airflow, ensuring a longer lifespan and stable performance. The robust housing is made of galvanized steel and fully insulated for quiet operation, even at high air outputs. This fan is suitable for outdoor installation and designed for continuous use at medium temperatures up to 120 °C, making it versatile.
Experience the High Quality of Ruck
Ruck Ventilatoren GmbH is a German specialist in ventilation technology with over 25 years of experience. As a market leader in energy-efficient fans, Ruck develops innovative products that meet the strictest ERP guidelines. With more than 300 employees, Ruck guarantees quality, reliability, and continuous technical innovation.
Features and Specifications
- Efficient diagonal fan with redundant operation
- Optimized aerodynamics via CFD simulation
- Sound-insulated housing made of galvanized sheet steel
- Built-in ETAMASTER for maximum yield
- Continuously adjustable EC motor outside the airflow
- Suitable for outdoor installation and temperatures up to 120°C
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Ruck EM DUO dubbele buisventilatoren geïsoleerd |
| GTIN | 4061199044264 |
| Manufacturer's item number | EM DUO 250 EC K 02 |
| Article number | 65172136 |
Specifications
| Category code | 35 |
| Length | 957 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 230 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 1530 m³/h |
| Suitable for frequency control | No |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 50 °C |
| Suitable for low-current control | Yes |
| Direct-current motor | Yes |
| 2-speed motor | No |
| Duct diameter | 250 mm |
