Good points
- Ø 180 - 160 mm
- Air tightness class 2
- Thermal and noise reducing solution
- Cost-saving due to short installation time
Thermoduct insulated T-piece 90 degrees with a diameter of 180 mm and spigot to 160 mm
This Thermoduct T-piece is equipped with a galvanic metal pipe with an outer casing of thermal insulation material with a 13 mm closed cell structure.
The Thermoduct insulated T-piece is suited for air duct systems and Ideal for the supply and extraction of outdoor air. Can be used with an MVHR installation or air source heat pump. The Thermoduct insulated ventilation pipe and accessories are developed and produced by Econox.
Prefab solution
Thermoduct is thé prefab solution for the installation of insulated, silent and energy efficient ventilation. The T-piece is prefabricated and insulated which makes the installation much easier. This also reduces installation time and therefore saves costs.
Reduction of heat loss and no condensation
Thermoduct is an air duct system with a high-quality thermal insulating casing. The casing ensures that heat loss is reduced and due to the dense cell structure of 13 mm, water vapor cannot be transferred. Thermoduct regulates temperature differences between the indoor and outdoor air, which makes condensation unlikely to occur.
Easy to install
Thermoduct stands for airtight installation. The Thermoduct products are provided with rubber seals and straps and as a result the Thermoduct fittings achieve air tightness class D or ATC 2. Thanks to the safe connection with rubber sealing and the convenient vapor-tight sealing strips, there is no need for any taping. The inner pipe is also galvanised and therefore easy to clean.
Noise reduction
Thanks to the acoustic properties of the insulating casing, noise is reduced in the ventilation ducts, resulting in a silent ventilation system. This makes it the solution for installations that meet the strict noise requirements of the 2012 Building Decree (max. 30dB(A))).
| Brand | Econox |
| Category | Thermoduct spiral ducts 90 degree T-pieces |
| GTIN | 8719544262424 |
| Manufacturer's item number | 11325126 |
| Article number | 11325126 |
Specifications
| Category code | 214 |
| Model | Uninsulated duct |
| Material duct | Steel |
| Material quality duct | Other |
| Wall thickness duct | 0.5 mm |
| Outer surface protection | Sendzimir galvanised |
| Inner surface protection | Sendzimir galvanised |
| Perforated inner wall | No |
| Outside colour | Grey |
| Design form | T-piece |
| Reverse (negative) T-piece model | No |
| Nominal duct diameter, connection 1 | 180 mm |
| Connection 1 | Insert end |
| Nominal duct diameter, connection 2 | 160 mm |
| Connection 2 | Insert end |
| Nominal duct diameter, connection 3 | 160 mm |
| Connection 3 | Insert end |
| With pre-mounted seal | Yes |
| Eccentric | No |
| Angle | 90 ° |
| Working length connection 1 | 220 mm |
| Working length connection 2 | 15 mm |
| Working length connection 3 | 15 mm |
| Insert length connection 1 | 35 mm |
| Insert length connection 2 | 35 mm |
| Insert length connection 3 | 35 mm |
| Air tightness class according to EN 1751 | D |
| Embeddable in concrete | No |
| Anti-bacterial treatment | No |
| Antistatic version | No |
| Diameter | 180 mm |
| Diameter 2 | 160 mm |
| Type of insulation | Thermoduct insulated 13mm |
