Good points
- Brand: Ruck fans
- Up to 15750 m3/h
- F400 smoke fan
- 200 °C continua
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Exhaust Roof extractor fans |
| GTIN | 4061199030540 |
| Manufacturer's item number | 150564 |
| Article number | 65150564 |
Specifications
| Number of phases | 3~ |
| Number of poles | 4 |
| Type of motor control | F |
| Category code | 35 |
| Weight | 121 kg |
| IP Motor | IP55 |
| Insulation Class Motor | F |
| Max. Operating Current | 8.5 A |
| Max. pressure | 1280 Pa |
| Max. Air Volume | 15750 m³/h |
| Max. Current Consumption | 8.5 A |
| Max. power consumption | 4112 W |
| Max. Static Efficiency | 57.6 % |
| Max. allowed Frequency (3˜ motors) | 50 Hz |
| Max. allowed Medium Temperature | 200 °C |
| Max. allowed Medium Temperature at Rated Current | 200 °C |
| Max. allowed Ambient Temperature | 50 °C |
| Max. allowed Ambient Temperature at Rated Current | 50 °C |
| Max. number of revolutions | 1485 1/min |
| Max. Total Efficiency | 58.2 % |
| Min. Operating Temperature | -20 °C |
| Motor type | 3~ |
| Nominal frequency | 50 Hz |
| Rated Speed | 1460 1/min |
| Nominal power consumption | 4112 W |
| Nominal voltage | 400 V |
| Nominal current | 8.1 A |
| Direction of blow out | Horizontal |
