Orcon Humidity Control Sensor 15RF – Recessed
The Orcon humidity control sensor 15RF – recessed is a smart sensor for relative humidity, designed to automatically control your ventilation system as humidity rises. With its 230 V power supply and wireless (RF) communication, the sensor is easy to install and provides optimal comfort and protection against moisture and mould formation. Note! The Orcon humidity control sensor 15RF – recessed is only suitable for units manufactured in 2025 or later.
Benefits and Features
- Automatic humidity control: In auto mode, the ventilation switches to a higher setting when the relative humidity exceeds approx. 80 % RH for optimal air quality.
- Wireless RF signal (868 MHz): Easily connects with all Orcon fans from 2025 onwards, without additional wiring.
- 230 V direct power supply: No external power supply or batteries needed; low power consumption of approx. 0.6 W.
- LED status indication: LEDs display ventilation level and status, with an automatic dimming function for visual comfort.
- Compact size: Measures 50 × 50 × 30 mm and fits in a standard flush-mounted box.
- Connection: The Orcon CO₂ control sensor pairs wirelessly with the unit but always requires a 230V power supply to operate.
Applications and Usage
The Orcon humidity control sensor 15RF – recessed is designed for rooms such as bathrooms, toilets, kitchens, and utility rooms where humidity levels frequently rise. Ideal for both new builds and renovation projects with automatic or demand-controlled ventilation.
Practical Information
This sensor measures relative humidity within a range of 0–100 % RH (functional use up to 90–95 % RH non-condensing), with an accuracy of ±5 % at 11–89 % RH. Connected to 230 V via screw terminals, it transmits wireless signals to the ventilation system. Thanks to its compact dimensions (50×50×30 mm), installation is quick and tidy.
Why Choose This Product
The Orcon humidity control sensor 15RF – recessed offers a reliable and energy-efficient solution to prevent moisture problems and mould growth. With automatic control of your ventilation during humidity increases, you enjoy fresh air effortlessly. Perfectly suited to any interior thanks to its recessed mounting and sleek design.
| Brand | Orcon |
| Category | Parts for Orcon Mechanical Ventilation |
| GTIN | 8720701076051 |
| Manufacturer's item number | 21800030 |
| Article number | 19130040 |
Specifications
| Category code | 108 |
| Scope of application | Room |
| With mounting material | Yes |
| Suitable for wall mounting | Yes |
| Suitable for ceiling mounting | No |
| Suitable for duct mounting | No |
| Suitable for tube mounting | No |
| Suitable for air | Yes |
| Suitable for liquids | No |
| Suitable for gases | No |
| With housing | Yes |
| Cover attachment | Snapped on |
| Sensor element inside housing | Yes |
| Sensor element outside housing | No |
| Fixed cable to sensor | No |
| Material element | Other |
| Technology | Capacitive polymer sensor |
| Active temperature measurement | No |
| Passive temperature measurement | No |
| Average temperature measuring | No |
| Number of measuring points | 1 |
| Measurement of CO2 | No |
| Measurement of VOC | No |
| Measurement of relative air humidity | Yes |
| Measurement of absolute air humidity | No |
| Enthalpy measurement | No |
| Measurement of dewpoint | No |
| Particulate matter measurement (PM) | No |
| Number of measuring ranges | 1 |
| Offset setting possible | No |
| Trend representation | No |
| Error registration possible | No |
| Tolerance | 5 % |
| Potentiometer with adjustment knob | No |
| Supporting protocol for BACnet | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for MP (multi point) | No |
| Supporting protocol for KNX | No |
| LoRa technology | No |
| NFC (Near Field Communication) | No |
| Bluetooth | No |
| Wi-Fi-compatible | No |
| Standby push button | No |
| Wireless | Yes |
| With display | No |
| Type of power supply | None |
| Type of electric connection | Screw connection |
| Rated supply voltage AC (min) | 195 V |
| Rated supply voltage AC (max) | 253 V |
| With reverse polarity protection | No |
| Max. ambient humidity (non-condensing) | 90 % |
| Explosion-proof | No |
| Degree of protection (IP) | IP21 |
| Housing height | 50 mm |
| Housing width | 50 mm |
| Housing depth | 30 mm |
| Housing colour | White |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| IFTTT support available | No |
