Motorised Shut-off Damper with Spring Return for ETA K / PHE 4200/5000 V - MAK V E 01 02 FR
The MAK V E 01 02 FR is an insulated motorised shut-off damper, designed for use with the ETA K / PHE 4200 V and ETA K / PHE 5000 V air handling units. The damper is made from galvanized sheet steel and equipped with an actuator featuring a spring return function. This actuator operates on 230 V, 50/60 Hz and delivers a torque of 4 Nm. The spring return ensures the damper automatically closes in the event of a power failure, contributing to a safe and reliable installation.
Main Features
- Motorised shut-off damper: Ensures secure air sealing during power outage.
- Material: Insulated version made from galvanized sheet steel.
- Control: Open/close operation with automatic return via spring mechanism.
- Actuator: 230 V, 50/60 Hz, 4 Nm torque.
Application
Suitable as a supply or exhaust damper in combination with the ETA K / PHE 4200 V and ETA K / PHE 5000 V air handling units.
| Brand | Ruck ventilatoren GmbH |
| Category | Motorised shut-off valve |
| GTIN | 4061199043397 |
| Manufacturer's item number | MAK V E 01 02 FR |
| Article number | 65171108 |
Specifications
| Category code | 121 |
| Material | Steel |
| Surface protection | Other |
| Nominal duct width | 897 mm |
| Nominal duct height | 564 mm |
| Connection 1 | Duct end |
| Connection 2 | Duct end |
| Lacquered | No |
| Can be used on solid walls/floors | No |
| Can be used directly against walls/floors | No |
| Can be used in separating partitions | No |
| Can be used at a distance from walls | No |
| Length | 115 mm |
