RRP 1,651.74
1,189.25
-28%
Delivery time: 5 weeks
- The largest collection in the United Kingdom
- 100 day return period
- Customer review 9/10
- Safe shopping with Trustedshops
Pay safe and fast with:
Good points
- For use with an air handling unit
- Galvanized sheet steel, insulated
- Open-close, with spring return
- 230 V Servo Motor, 5 Nm
Motorised Shut-Off Damper with Spring Return for ETA K / PHE 3500 F - MAK F E 05 FR
The MAK F E 05 FR is an insulated motorised shut-off damper specifically designed for use with the ETA K / PHE 3500 F air handling unit. The damper is constructed from galvanised sheet steel and is equipped with a spring return actuator that automatically closes in the event of a power failure. The actuator operates on 230 V, 50/60 Hz and delivers a torque of 4 Nm. A reliable solution for applications where safety and automatic airtight sealing are essential.
Main Features
- Motorised shut-off damper: For automatic airtight sealing during power loss.
- Material: Insulated construction made of galvanised sheet steel.
- Control: Open/close operation with spring return function.
- Actuator: 230 V, 50/60 Hz, 4 Nm.
Application
Ideal as a supply or exhaust damper in combination with the ETA K / PHE 3500 F air handling unit.
| Brand | Ruck ventilatoren GmbH |
| Category | Motorised shut-off valve |
| GTIN | 4061199043809 |
| Manufacturer's item number | MAK F E 05 FR |
| Article number | 65171505 |
Specifications
| Category code | 121 |
| Material | Steel |
| Surface protection | Other |
| Connection 1 | Duct end |
| Connection 2 | Duct end |
| Can be used on solid walls/floors | No |
| Can be used directly against walls/floors | No |
| Can be used in separating partitions | No |
| Can be used at a distance from walls | No |
| Length | 110 mm |
