Good points
- Brand: Ruck
- 11 kw
- Supply voltage 400 V 3ph
- Output voltage 0 - 400 V 3
Frequency Converter 400V 3ph IP20 – FU 110 01
The FU 110 01 is a frequency converter designed for variable speed control of motor speed in ventilation systems. This converter is suitable for a mains voltage of 400 V three-phase (50/60 Hz) and provides an output voltage of 0 to 400 V three-phase. The unit is equipped with motor and converter protection and is designed for installation in a control cabinet. With an IP20 protection class, the converter is suitable for use in dry, dust-free indoor environments.
More technical information about this product can be found in the attachment under the "Documents" tab.
| Brand | Ruck ventilatoren GmbH |
| Category | Frequency Inverters for Axial Fans |
| GTIN | 4061199043564 |
| Manufacturer's item number | FU 110 01 |
| Article number | 65171247 |
Specifications
| Category code | 121 |
| Mains frequency | 50/60 Hz |
| Number of phases input | 3 |
| Number of phases output | 3 |
| Max. output voltage | 400 V |
| Nominal output current I2N | 24 A |
| Power consumption | 11000 kW |
| Number of analogue outputs | 1 |
| Number of analogue inputs | 1 |
| Number of digital outputs | 1 |
| Number of digital inputs | 3 |
| With control element | Yes |
| Application in industrial area permitted | Yes |
| Application in domestic- and commercial area permitted | Yes |
| Supporting protocol for TCP/IP | No |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for CAN | No |
| Supporting protocol for INTERBUS | No |
| Supporting protocol for ASI | No |
| Supporting protocol for KNX | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for Data-Highway | No |
| Supporting protocol for DeviceNet | No |
| Supporting protocol for SUCONET | No |
| Supporting protocol for LON | No |
| Supporting protocol for PROFINET IO | No |
| Supporting protocol for PROFINET CBA | No |
| Supporting protocol for SERCOS | No |
| Supporting protocol for Foundation Fieldbus | No |
| Supporting protocol for EtherNet/IP | No |
| Supporting protocol for AS-Interface Safety at Work | No |
| Supporting protocol for DeviceNet Safety | No |
| Supporting protocol for INTERBUS-Safety | No |
| Supporting protocol for PROFIsafe | No |
| Supporting protocol for SafetyBUS p | No |
| Supporting protocol for BACnet | No |
| Supporting protocol for other bus systems | No |
| With optical interface | No |
| With PC connection | No |
| Integrated breaking resistance | No |
| 4-quadrant operation possible | No |
| Type of converter | Direct converter |
| Degree of protection (IP) | IP20 |
| Height | 261 mm |
| Width | 187 mm |
| Depth | 190 mm |
