Good points
- For supply and removal
- Incl. bird netting
- Aluminum alloy
Aluminium Exterior Wall Vent 150x150 mm - RAL 9016
The aluminium exterior wall vent is specifically designed for the supply and exhaust of air through exterior walls. The vent is suitable for both residential and commercial buildings where fresh air needs to be supplied or contaminated air extracted. The exterior wall vent is corrosion-resistant and features a robust construction, ensuring it does not deform.
Practical Information
The exterior wall vent measures 150x150 mm with an overall dimension of 180x180 mm, allowing it to neatly cover the wall opening. The depth is 19.5 mm. The vent is powder-coated in RAL 9016, and is also available in RAL 8016, 1015, 9005, or uncoated. It is supplied with a coarse mesh bird guard to prevent birds or large insects from entering the ventilation opening.
Installation
For installation, cut or drill a square opening of 148x148 mm in the wall. The vent is then placed over this opening and fixed to the wall with four screws, one in each corner. On the interior side, connect the vent to the ventilation duct through the 148x148 mm opening.
| Brand | Econox |
| Category | Aluminum Exterior Vent covers |
| GTIN | 8719544322838 |
| Manufacturer's item number | 35001852 |
| Article number | 35001852 |
Specifications
| Category code | 173 |
| Shape | Square |
| Material | Aluminium |
| Surface protection | Lacquered |
| Nominal duct width | 148 mm |
| Nominal duct height | 148 mm |
| Front width | 180 mm |
| Front height | 180 mm |
| Built-in depth | 19.5 mm |
| With bird wire | Yes |
| With insect netting | No |
| With pressure relief blow-out valve | No |
| With pressure relief suction valve | No |
| With contrarotating valve section | No |
| With synchronised rotating valve section | No |
| With built-in window | No |
| Lockable | No |
| Motor-controlled | No |
| Colour | White |
| RAL-number | 9016 |
