Good points
- Brand: Ruck
- EC motor
- Up to 8700 m3/h
- Speed controllable
Box Fan Motor Outside Linear Flow - MPC TI 500 EC K01
The Ruck box fan MPC TI 500 EC K01 is designed for powerful and reliable ventilation in professional environments. Thanks to the backward-curved centrifugal impeller and the linear airflow principle, this fan ensures direct and efficient air guidance through the housing. The EC motor, positioned outside the airflow, prevents contamination from grease, moisture, or heat, contributing to a longer lifespan and lower maintenance needs. The motor is infinitely adjustable via a 0-10V signal, allowing you to perfectly tune the air volume to your application.
High Quality
The MPC TI 500 EC K01 features a double-walled, insulated housing made of galvanized steel, which provides sound dampening and thermal insulation. The underside of the housing is equipped with an integrated drain for condensate and grease, ideal for applications with increased humidity or grease load. The fan is suitable for continuous operation at medium temperatures up to 120 °C. Thanks to the maintenance-friendly design with a removable fan unit, cleaning and inspection can be performed quickly and easily.
Ruck Ventilatoren GmbH is a leading German manufacturer with over 25 years of experience in energy-efficient ventilation technology. With more than 300 employees, Ruck develops innovative ventilation solutions daily that meet the strictest requirements regarding energy consumption, reliability, and safety. All products comply with current ERP guidelines.
Features and Specifications
- Centrifugal fan with backward-curved impeller
- Linear airflow through the housing
- Double-walled, insulated housing made of galvanized steel
- Integrated drain for condensate and grease
- EC motor outside the airflow, infinitely adjustable
- Suitable for medium temperatures up to 120°C in continuous operation
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Heat-resistant box fans |
| GTIN | 4061199044271 |
| Manufacturer's item number | MPC TI 500 EC I K 01 |
| Article number | 65172139 |
Specifications
| Category code | 35 |
| Length | 900 mm |
| Connection | Insert end |
| Width | 900 mm |
| Height | 900 mm |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 8700 m³/h |
| Power consumption | 1478 kW |
| Suitable for frequency control | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 50 °C |
| Suitable for low-current control | Yes |
| Direct-current motor | Yes |
| 2-speed motor | No |
