Good points
- Brand: Ruck
- AC motor
- Up to 7790 m3/h
- Frequency controlled
Box Fan Motor Outside Airflow – MPC T 450 D4 K01
The Ruck box fan MPC T 450 D4 K01 is a robust and efficient ventilation solution, equipped with a powerful IE3 motor that is positioned outside the airflow. This prevents contaminated or warm air from flowing through the motor, ensuring a longer lifespan and less maintenance. The fan utilizes a backward-curved centrifugal impeller that guarantees stable and powerful air displacement. Thanks to the removable side panels and variable discharge direction, the MPC T 450 D4 K01 can be mounted flexibly, both horizontally and vertically. The motor is infinitely adjustable, allowing for precise tuning to your ventilation needs.
High Quality
The MPC T 450 D4 K01 features a double-walled and insulated housing made of galvanized steel, providing excellent thermal and acoustic insulation. The underside is equipped with an integrated drain for condensate and grease, ideal for environments with humid or contaminated airflows. The fan is suitable for continuous operation at medium temperatures up to 120 °C. Thanks to the smart design with removable side panels, maintenance is easy to perform, and the flexible air direction allows for efficient integration into any duct system.
Ruck Ventilatoren GmbH is a renowned German manufacturer with over 25 years of experience in high-quality ventilation technology. With more than 300 employees, Ruck develops energy-efficient and future-proof solutions daily. All products are designed according to current ERP guidelines and meet the strictest requirements for sustainability and performance.
Features and Specifications
- Centrifugal fan with backward-curved impeller
- Removable side panels and variable discharge direction
- Double-walled, insulated housing made of galvanized steel
- Integrated drain for condensate and grease
- IE3 motor outside the airflow, infinitely adjustable
- Suitable for medium temperatures up to 120°C in continuous operation
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Heat-resistant box fans |
| GTIN | 4061199044561 |
| Manufacturer's item number | MPC T 450 D4 I K 01 |
| Article number | 65172726 |
Specifications
| Category code | 35 |
| Length | 700 mm |
| Connection | Insert end |
| Width | 700 mm |
| Height | 700 mm |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 7790 m³/h |
| Power consumption | 1569 kW |
| Suitable for frequency control | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | Yes |
| Direct-current motor | Yes |
| 2-speed motor | No |
| Duct diameter, suction | 500 mm |
| Duct diameter, exhaust | 500 mm |
