Good points
- Brand: Ruck
- EC motor
- Up to 8440 m3/h
- Speed controllable
Box Fan Motor Outside Airflow – MPC T 500 EC K01
The Ruck box fan MPC T 500 EC K01 is a powerful and efficient ventilation solution for professional applications where high air output and flexibility are required. The fan is equipped with a backward-curved centrifugal impeller and an energy-efficient EC motor that is positioned outside the airflow. This protects the motor from contamination and heat, ensuring a longer lifespan and minimal maintenance needs. The air discharge is variably adjustable, making it easy to adapt the fan to the desired installation position. The motor is continuously adjustable via a 0-10V signal for maximum control over the air volume.
High Quality
The MPC T 500 EC K01 features a double-walled, insulated housing made of galvanized steel. This provides excellent sound insulation and thermal protection. An integrated drain for condensate and grease is installed at the bottom, making the system suitable for demanding applications such as kitchens or industrial installations. The fan is designed for continuous operation with medium temperatures up to 120 °C. Thanks to its maintenance-friendly design and flexible discharge direction, this fan can be easily integrated into various ventilation systems.
Ruck Ventilatoren GmbH is a leading German manufacturer with over 25 years of experience in developing sustainable ventilation solutions. With more than 300 employees, the company works daily on innovative technologies that meet the highest standards for energy efficiency and safety. The MPC T 500 EC K01 is also designed according to current ERP guidelines.
Features and Specifications
- Centrifugal fan with backward-curved impeller
- Variable discharge direction for flexible installation
- Double-walled, insulated housing made of galvanized steel
- Integrated drain for condensate and grease
- EC motor outside the airflow, continuously adjustable
- Suitable for medium temperatures up to 120°C in continuous operation
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Heat-resistant box fans |
| GTIN | 4061199044295 |
| Manufacturer's item number | MPC T 500 EC I K 01 |
| Article number | 65172147 |
Specifications
| Category code | 35 |
| Length | 700 mm |
| Connection | Insert end |
| Width | 700 mm |
| Height | 700 mm |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 8440 m³/h |
| Power consumption | 1537 kW |
| Suitable for frequency control | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 50 °C |
| Suitable for low-current control | Yes |
| Direct-current motor | Yes |
| 2-speed motor | No |
| Duct diameter, suction | 500 mm |
| Duct diameter, exhaust | 500 mm |
