- Brand: Ruck fans
- EC motor energy efficient
- Up to 2290 m3/h
- 120 °C continuous
Ruck® box fan with linear airflow and EC motor
The Ruck® box fan (MPC EC TI series) has an energy-efficient motor, this EC motor is mounted outside the air stream. The advantage of this is that any dirty and contaminated air (grease) is not discharged via the motor. The EC box fan with motor outside the air stream is therefore often used in the catering industry. This box fan has a linear airflow, so the direction of the air stream remains the same. The motor can be operated with the variable speed control (MTP 20) or with constant pressure control by means of a 0-10V connection. If you use the reducer, we also recommend the Ruck® fast clamp to reduce vibrations and noise through the duct.
The box fan is equipped with 30 mm insulation and has internal electronic temperature control to prevent burn out. The energy-efficient box fan can be mounted via Ruck®'s base frame and has a variable discharge direction. The MPC EC TI series is available in capacities ranging from 2290 m³/h to a maximum of 6800 m³/h and with diameters ranging from 250 mm to 400 mm respectively.
Ruck ventilatoren GmbH, is a leading German company with more than 25 years of experience. They are market leaders in the field of energy-efficient box fans with EC motor outside the air stream. With more than 300 enthusiastic employees, they work together on new developments and techniques on a daily basis. The company ensures quality assurance in order to deliver a great product with the latest ERP (Energy Related Product) requirements.
- Linear airflow
- EC motor outside the air stream
- Integrated electronics
- 30 mm insulation
- With condensation and grease extraction
- With adjustable speed
| Brand | Ruck ventilatoren GmbH |
| Category | Heat-Resistant Box Fan for Hospitality |
| GTIN | 4061199029872 |
| Manufacturer's item number | 146152 |
| Article number | 65146152 |
Specifications
| Number of phases | 1~ |
| Type of motor control | 0-10V |
| Category code | 35 |
| Weight | 37.7 kg |
| IP Motor | IP54 |
| Insulation Class Motor | F |
| Max. Operating Current | 3.5 A |
| Max. pressure | 1250 Pa |
| Max. Air Volume | 2290 m³/h |
| Max. Current Consumption | 3.5 A |
| Max. power consumption | 756 W |
| Max. Static Efficiency | 47 % |
| Max. allowed RPM (with EC-motors) | 4000 1/min |
| Max. allowed Medium Temperature | 120 °C |
| Max. allowed Medium Temperature at Rated Current | 120 °C |
| Max. allowed Ambient Temperature | 50 °C |
| Max. allowed Ambient Temperature at Rated Current | 50 °C |
| Max. number of revolutions | 4000 1/min |
| Max. Total Efficiency | 47.9 % |
| Min. Operating Temperature | -20 °C |
| Motor Protection | TEC |
| Motor type | EC |
| Nominal frequency | 50 Hz |
| Rated Speed | 4000 1/min |
| Nominal power consumption | 756 W |
| Nominal voltage | 230 V |
| Nominal current | 3.4 A |
| Direction of blow out | In line |
