Good points
- Brand: Ruck fans
- AC motor
- Up to 7890 m3/h
- F400 smoke fan
Ruck smoke extractor box fan swing-out and frequency-controlled
The Ruck smoke box fan (MPS DF series) has a frequency-driven motor, this motor is mounted outside the air stream. The advantage of this is that any dirty and contaminated air or gas of up to 200 degrees Celsius is not discharged via the motor. The fan can even handle a temperature of 400 degrees Celsius temporarily! The smoke box fan with motor outside the air stream is therefore often used in the catering industry or in connection with grease. Attention: the fan must be controlled with a frequency converter. If desired, the frequency converter can be controlled with a variable potentiometer.
For maintenance, the energy-efficient box fan is easy to open, and there is also condensation and grease extraction. The MPS DF series is available with capacities ranging from 1960 m3/h up to a maximum of 11840 m3/h.
Ruck ventilatoren GmbH, is a leading German company with more than 25 years of experience. They are market leaders in the field of energy-efficient box fans with voltage control and EC motor. With more than 300 enthusiastic employees, they work together on new developments and techniques on a daily basis. The company ensures quality assurance in order to deliver a great product with the latest ERP (Energy Related Product) requirements.
- Frequency-controlled motor outside the air stream
- Up to 200°C medium temperature
- With condensation and grease extraction
- Ventilation unit swivels outwards
- With adjustable speed
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Box Fan |
| GTIN | 4061199029858 |
| Manufacturer's item number | 145876 |
| Article number | 65145876 |
Specifications
| Number of phases | 3~ |
| Number of poles | 4 |
| Type of motor control | F |
| Category code | 35 |
| Weight | 112.7 kg |
| IP Motor | IP55 |
| Insulation Class Motor | F |
| Max. Operating Current | 3 A |
| Max. pressure | 855 Pa |
| Max. Air Volume | 7890 m³/h |
| Max. Current Consumption | 3 A |
| Max. power consumption | 1504 W |
| Max. Static Efficiency | 53.7 % |
| Max. allowed Frequency (3˜ motors) | 50 Hz |
| Max. allowed Medium Temperature | 200 °C |
| Max. allowed Medium Temperature at Rated Current | 200 °C |
| Max. allowed Ambient Temperature | 50 °C |
| Max. allowed Ambient Temperature at Rated Current | 50 °C |
| Max. number of revolutions | 1490 1/min |
| Max. Total Efficiency | 57.8 % |
| Min. Operating Temperature | -20 °C |
| Motor type | 3~ |
| Nominal frequency | 50 Hz |
| Rated Speed | 1450 1/min |
| Nominal power consumption | 1504 W |
| Nominal voltage | 400 V |
| Nominal current | 2.8 A |
| Direction of blow out | Shifted by 90° compared to suction |
