- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 900 mm Duct Fan Flue Gas F400 – AL 900 D84U F4 01 CFG
The AL 900 D84U F4 01 CFG from Ruck is an innovative and highly efficient axial fan, designed for medium pressure applications. By utilizing the latest numerical design techniques, system efficiency has been enhanced and the operating range expanded. Thanks to the adjustable blades, this fan is widely applicable in both commercial buildings and industrial ventilation systems.
Optimized Design with 2-Stage IE3 Motor
The fan features a robust, lightweight construction that simplifies installation and maintenance. The IE3 motor is adjustable in 2 stages via a Dahlander connection, ensuring flexible and energy-efficient operation. The aerodynamically shaped blades contribute to a powerful airflow and increased efficiency. The AL 900 D84U F4 01 CFG is certified for flue gas discharge up to 400 °C (F400) and suitable for continuous operation at air temperatures up to 60 °C. This model is ideal for dual-use applications such as standard ventilation and flue gas and heat discharge. It is supplied without a terminal box, but with a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of high-quality ventilation systems. With a focus on innovation, energy efficiency, and sustainability, all products comply with current ERP guidelines and deliver reliable performance under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321978 |
| Manufacturer's item number | AL 900 D84U F4 01 CFG |
| Article number | 65170775 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 37700 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
