Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 900 mm Duct Fan Flue Gas F400 – AL 900 D4 F4 03 CFG
The AL 900 D4 F4 03 CFG from Ruck is an innovative, high-efficiency axial fan specifically designed for medium pressure applications. Thanks to the use of the latest numerical design techniques, system efficiency has been optimized and the operating range expanded. The adjustable blades make this fan versatile for use in commercial buildings and industrial ventilation systems.
Optimized Design for Flue Gas Exhaust and General Ventilation
This fan features a lightweight, robust design that allows for easy installation and efficient handling. The integrated IEC standard motor is suitable for frequency control, ensuring flexible and energy-efficient operation. The aerodynamically shaped blades contribute to high airflow and increased efficiency. The AL 900 D4 F4 03 CFG is certified for flue gas exhaust up to 400 °C (F400) and is suitable for continuous operation at air temperatures up to 60 °C. This makes it ideal for dual-use applications such as standard ventilation and smoke and heat exhaust in case of fire. It is supplied without a terminal box but includes a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of high-quality ventilation solutions. All products are designed with a focus on sustainability, innovation, and energy efficiency, complying with current ERP guidelines. Ruck guarantees reliable performance in a variety of demanding applications.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321954 |
| Manufacturer's item number | AL 900 D4 F4 03 CFG |
| Article number | 65170766 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 58078 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
