Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 900 mm Duct Fan Flue Gas F400 – AL 900 D4 F4 02 CFG
The AL 900 D4 F4 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. By utilizing advanced numerical design techniques, system efficiency has been enhanced and the operating range expanded. The adjustable blades make this fan versatile for use in commercial buildings and industrial ventilation systems.
Optimized Design for Flue Gas Exhaust and Standard Ventilation
This fan features a lightweight and robust design that simplifies installation and maintenance. The integrated IEC standard motor is suitable for frequency control, allowing for flexible and energy-efficient operation. The aerodynamically shaped blades ensure a powerful airflow and increased efficiency. The AL 900 D4 F4 02 CFG is certified for flue gas exhaust up to 400 °C (F400) and is suitable for continuous operation at air temperatures up to 60 °C. This makes it particularly suitable for dual-use applications: both daily ventilation and smoke and heat extraction in case of fire. It is supplied without a terminal box, but with a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of ventilation solutions. All products are developed with a focus on energy efficiency, sustainability, and reliability, complying with current ERP guidelines. Ruck guarantees stable performance even under the most demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321947 |
| Manufacturer's item number | AL 900 D4 F4 02 CFG |
| Article number | 65170763 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 46279 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
