Axial 900 mm Duct Fan Flue Gas F300 – AL 900 D84U F3 03 CFG
The AL 900 D84U F3 03 CFG from Ruck is an innovative and high-efficiency axial fan, developed for both flue gas discharge and daily ventilation. Thanks to the use of the latest numerical simulation techniques, the design has been optimized for maximum system efficiency. The adjustable blade positions provide a wide operational range, making this fan suitable for various applications. This model is F300 certified and suitable for continuous use up to 60 °C. Thus, it is an ideal dual-use solution: for normal air exchange and flue gas heat discharge in case of fire.
Robust Design with Optimized Weight
The AL 900 D84U F3 03 CFG is designed with a robust yet lightweight construction that simplifies installation and maintenance. The design is optimized to save weight without compromising performance or durability. The fan is equipped with an energy-efficient IE3 motor with two-speed control via a Dahlander switch. Thanks to the aerodynamically shaped rotor and stator blades, this model achieves high efficiency in medium pressure applications. This makes it an excellent choice for larger commercial and industrial installations where reliability and flexibility are essential.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of expertise in ventilation technology. With over 300 employees, the company works daily on innovative solutions that meet the highest standards in fire safety, energy efficiency, and sustainability. The AL 900 D84U F3 03 CFG complies with all current ERP guidelines and is designed for stable performance, even under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322593 |
| Manufacturer's item number | AL 900 D84U F3 03 CFG |
| Article number | 65171194 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 55640 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
