Good points
- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 900 mm Duct Fan Flue Gas F300 – AL 900 D84U F3 02 CFG
The AL 900 D84U F3 02 CFG from Ruck is an innovative and highly efficient axial fan, specifically designed for flue gas extraction and daily ventilation. Thanks to the application of the latest numerical calculation methods, this model is optimized for maximum system efficiency. The adjustable blade positions provide a wide operating range, making this fan versatile for various applications. The model is F300 certified and suitable for continuous use up to 60 °C, making it an ideal dual-use solution: for air exchange and flue gas heat extraction in case of fire.
Robust Design with Optimized Weight
The AL 900 D84U F3 02 CFG is designed with a robust yet lightweight construction, simplifying installation and making maintenance efficient. The optimized design ensures weight reduction without compromising performance or durability. The fan is equipped with an energy-efficient IE3 motor that can be controlled in two speed stages via a Dahlander switching. Thanks to the aerodynamically shaped rotor and stator blades, this model delivers high efficiency in medium pressure applications. Thus, this fan is excellently suited for larger commercial and industrial systems where reliability is paramount.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in high-quality ventilation technology. With over 300 employees, the company develops products that meet the strictest standards in fire safety and energy efficiency. The AL 900 D84U F3 02 CFG also complies with current ERP guidelines and is designed for reliable performance under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322586 |
| Manufacturer's item number | AL 900 D84U F3 02 CFG |
| Article number | 65171191 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 58775 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
