Good points
- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 900 mm Duct Fan Flue Gas F300 – AL 900 D84U F3 01 CFG
The AL 900 D84U F3 01 CFG from Ruck is an innovative and highly efficient axial fan, specifically designed for flue gas extraction and daily ventilation. Thanks to the use of the latest numerical simulation techniques, the design has been optimized for maximum system efficiency. The adjustable blade positions provide a wide operating range, making this fan suitable for various applications. This model is F300 certified and suitable for continuous use up to 60 °C. Thus, it is a reliable dual-use solution: applicable for regular air exchange and flue gas heat extraction during a fire.
Robust Design with Optimized Weight
The AL 900 D84U F3 01 CFG is designed with a sturdy yet lightweight construction, making installation and maintenance easier. The optimized product design results in a lower weight without compromising performance or durability. The fan is equipped with an energy-efficient IE3 motor with two-speed control via a Dahlander connection. This allows for flexible and energy-saving operation. The aerodynamically shaped rotor and stator blades also ensure high efficiency in medium-pressure applications. An ideal choice for larger commercial and industrial installations.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in advanced ventilation technology. With over 300 employees, they develop high-quality products that meet the strictest standards in fire safety and energy efficiency. The AL 900 D84U F3 01 CFG also complies with current ERP guidelines and offers reliable performance, even under harsh conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322579 |
| Manufacturer's item number | AL 900 D84U F3 01 CFG |
| Article number | 65171186 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 37700 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
