Axial 900 mm Duct Fan Flue Gas F300 – AL 900 D6 F3 03 CFG
The AL 900 D6 F3 03 CFG from Ruck is an innovative and energy-efficient axial fan, designed for medium pressure applications. Thanks to the use of the latest numerical design techniques, system efficiency has been improved and the operating range has been expanded. The adjustable blades make this fan suitable for a variety of ventilation needs in commercial buildings and industry.
Optimized Design for Smoke and Heat Extraction
With a robust yet lightweight design, the fan is easy to install and maintain. The integrated IEC standard motor is suitable for frequency control, ensuring flexible and energy-saving operation. The aerodynamically optimized blades contribute to high airflow and improved efficiency. The AL 900 D6 F3 03 CFG is certified for flue gas extraction at temperatures up to 300 °C (F300) and is suitable for continuous operation at air temperatures up to 60 °C. This makes the fan ideal for dual-use applications, such as daily ventilation and smoke and heat extraction. It is supplied without a terminal box, but with a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of ventilation solutions. All products are developed with a strong focus on innovation, energy efficiency, and reliability. They comply with current ERP guidelines and deliver stable performance, even under the most demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322081 |
| Manufacturer's item number | AL 900 D6 F3 03 CFG |
| Article number | 65170823 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 54259 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
