- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 900 mm Duct Fan Flue Gas F300 – AL 900 D4 F3 05 CFG
The AL 900 D4 F3 05 CFG from Ruck is an innovative and highly efficient axial fan, designed for medium pressure applications. By utilizing the latest numerical design techniques, system efficiency has been enhanced and the operating range has been broadened. Thanks to the adjustable blades, this fan is versatile for use in both commercial buildings and industrial ventilation systems.
Optimized Design for Flue Gas Exhaust and Standard Ventilation
This fan features a lightweight, robust construction that simplifies installation and maintenance. The integrated IEC standard motor is suitable for frequency control, allowing for flexible and energy-efficient operation. The aerodynamically shaped blades ensure a powerful airflow and increased efficiency. The AL 900 D4 F3 05 CFG is certified for flue gas exhaust at temperatures up to 300 °C (F300) and is suitable for continuous operation at air temperatures up to 60 °C. This makes it ideal for dual-use applications such as daily ventilation and smoke and heat extraction. It is supplied without a terminal box, but with a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of high-quality ventilation systems. With a strong focus on innovation, energy efficiency, and reliability, all products comply with current ERP guidelines and deliver dependable performance under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322005 |
| Manufacturer's item number | AL 900 D4 F3 05 CFG |
| Article number | 65170794 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 65926 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
