Axial 900 mm Duct Fan – AL 900 D4 05 CFG
The AL 900 D4 05 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. Thanks to the use of the latest numerical design techniques, system efficiency has been optimized and the operating range expanded. The adjustable blades allow for versatile use in utility applications and industrial environments.
Optimized Design for Flexible and Efficient Air Movement
This fan features a lightweight and robust construction that ensures easy installation and reliable operation. The integrated IEC standard motor is suitable for frequency control, enabling energy-efficient and adaptable operation. The aerodynamically shaped blades contribute to a powerful airflow and increased efficiency. The AL 900 D4 05 CFG is suitable for continuous operation at air temperatures up to 60 °C, making it ideal for standard ventilation applications. It is supplied without a terminal box but includes a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a renowned German manufacturer of high-quality ventilation solutions. With a strong focus on innovation, energy efficiency, and sustainability, all products comply with current ERP guidelines and deliver consistent performance under various conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544321121 |
| Manufacturer's item number | AL 900 D4 05 CFG |
| Article number | 65170186 |
Specifications
| Category code | 35 |
| Length | 638 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 65926 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 900 mm |
