Good points

Brand: Ruck
AC motor
Standard temperature
Frequency controlled

Axial 900 mm Duct Fan – AL 900 D4 02 CFG

The AL 900 D4 02 CFG from Ruck is an innovative and highly efficient axial fan, designed for medium pressure applications. By utilizing the latest numerical design techniques, system efficiency has been enhanced and the operating range expanded. Thanks to the adjustable blades, this fan is widely applicable in commercial and industrial ventilation systems.

Optimized Design for Reliable Air Displacement

The fan features a lightweight, robust construction, ensuring easy installation and handling. The integrated IEC standard motor is suitable for frequency control, allowing for flexible and energy-efficient operation. The aerodynamically shaped blades contribute to high airflow and increased efficiency. The AL 900 D4 02 CFG is suitable for continuous operation at air temperatures up to 60 °C, making it a sustainable choice for standard ventilation applications. It is supplied without a terminal box, but includes a cable for connecting an external switch.

Reliable Quality from Ruck

Ruck Ventilatoren GmbH is a renowned German manufacturer of high-quality ventilation solutions. With a strong focus on innovation, energy efficiency, and reliability, all products comply with current ERP guidelines and deliver stable performance under various conditions.

More Information

Brand	Ruck ventilatoren GmbH
Category	Axial duct fan
GTIN	8719544321091
Manufacturer's item number	AL 900 D4 02 CFG
Article number	65170176

Specifications

Category code	35
Length	638 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IP55
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	46279 m³/h
Suitable for frequency control	Yes
Suitable for transformer control	Yes
Suitable for electronic control	No
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	900 mm
