Axial 800 mm Duct Fan Flue Gas F400 – AL 800 D84U F4 02 CFG
The AL 800 D84U F4 02 CFG from Ruck is an innovative and highly efficient axial fan, developed for flue gas extraction and daily ventilation. Thanks to the application of the latest numerical simulation techniques, the design has been optimized for maximum system efficiency. With adjustable blade angles, this fan offers a wide operating range, making it suitable for various applications. The model is F400 certified and suitable for continuous use up to 60 °C, making it an excellent dual-use fan: for both regular air exchange and smoke heat extraction in case of fire.
Robust Design with Optimized Weight
The AL 800 D84U F4 02 CFG is designed with a sturdy yet lightweight construction, which simplifies installation and facilitates maintenance. The product design has been optimized for weight reduction without compromising on performance or durability. The fan is equipped with an energy-efficient IE3 motor with two-speed control via a Dahlander connection. This combination allows for flexible and efficient operation. The aerodynamically shaped rotor and stator blades ensure high efficiency in medium-pressure applications. Ideal for commercial and industrial applications where safety and reliability are paramount.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in high-quality ventilation solutions. With a team of over 300 specialists, Ruck develops products that meet the strictest requirements in terms of fire safety, energy efficiency, and sustainability. The AL 800 D84U F4 02 CFG also complies with current ERP guidelines and is built for reliable performance under harsh conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322661 |
| Manufacturer's item number | AL 800 D84U F4 02 CFG |
| Article number | 65171230 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 44360 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
