Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 800 mm Duct Fan Flue Gas F400 – AL 800 D6 F4 01 CFG
The AL 800 D6 F4 01 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. Thanks to the application of the latest numerical design techniques, system efficiency has been improved and the operating range has been expanded. The adjustable blades make this fan versatile for use in commercial buildings and industrial ventilation systems.
Optimized Design for Smoke and Heat Extraction
This fan features a lightweight, robust construction that simplifies installation and maintenance. Equipped with an IEC standard motor suitable for frequency control, the AL 800 D6 F4 01 CFG can be operated flexibly and energy-efficiently. The aerodynamically shaped blades ensure a powerful airflow and increased efficiency. This model is certified for flue gas extraction up to 400 °C (F400) and suitable for continuous operation up to 60 °C, making it perfect for dual-use applications: standard ventilation and smoke and heat extraction in case of fire. It is supplied without a terminal box but includes a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of ventilation solutions. With a strong focus on innovation, energy efficiency, and sustainability, all products comply with current ERP guidelines. Ruck guarantees stable and reliable performance in demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321749 |
| Manufacturer's item number | AL 800 D6 F4 01 CFG |
| Article number | 65170618 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 27200 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
