Axial 800 mm Duct Fan Flue Gas F400 – AL 800 D4 F4 02 CFG
The AL 800 D4 F4 02 CFG from Ruck is an innovative and highly efficient axial fan designed for medium pressure applications. Thanks to the use of the latest numerical design techniques, system efficiency has been improved and the operating range has been expanded. The adjustable blades make this fan versatile for use in both commercial buildings and industrial ventilation environments.
Optimized Design for Flue Gas Exhaust and General Ventilation
This fan features a lightweight, robust design that simplifies installation and handling. The integrated IEC standard motor is suitable for frequency control, allowing for flexible and energy-efficient operation. The aerodynamically shaped blades ensure high airflow and increased efficiency. The AL 800 D4 F4 02 CFG is certified for flue gas exhaust at temperatures up to 400 °C (F400) and is suitable for continuous operation up to 60 °C – ideal for dual-use applications where both daily ventilation and smoke and heat exhaust are required. It is supplied without a terminal box, but with a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of high-quality ventilation solutions. With a focus on energy efficiency, innovation, and reliability, all products comply with current ERP guidelines and deliver consistent performance even under the most demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321695 |
| Manufacturer's item number | AL 800 D4 F4 02 CFG |
| Article number | 65170589 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 41280 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
