Axial 800 mm Duct Fan Flue Gas F300 – AL 800 D84U F3 01 CFG
The AL 800 D84U F3 01 CFG from Ruck is an innovative and highly efficient axial fan, designed for both flue gas extraction and daily ventilation. Utilizing the latest numerical simulation techniques, the design has been optimized for maximum system efficiency. Thanks to the adjustable blade positions, this model has a wide operating range, making it versatile for various applications. This fan is F300 certified and suitable for continuous use up to 60 °C, making it an ideal dual-use solution: for normal air exchange and flue gas heat extraction in case of fire.
Robust Design with Optimized Weight
The AL 800 D84U F3 01 CFG is constructed with a sturdy yet lightweight design. This makes installation straightforward and maintenance efficient. The product design has been optimized for weight reduction without compromising reliability or performance. The fan is equipped with an IE3 motor featuring two-speed control via a Dahlander connection, ensuring flexible and energy-efficient operation. The aerodynamically shaped rotor and stator blades provide high efficiency in medium pressure applications. Therefore, this fan is particularly suitable for medium to large commercial and industrial installations.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer known for its innovative ventilation solutions for many years. With over 300 employees, they develop high-quality products that meet the strictest standards for fire safety and energy efficiency. The AL 800 D84U F3 01 CFG also complies with current ERP guidelines and offers reliable performance, even under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322548 |
| Manufacturer's item number | AL 800 D84U F3 01 CFG |
| Article number | 65171173 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 38420 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
