Good points
- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 800 mm Duct Fan Smoke Gas F300 – AL 800 D4 F3 06 CFG
The AL 800 D4 F3 06 CFG from Ruck is an innovative axial fan with high efficiency, specifically designed for medium pressure applications. By utilizing the latest numerical design techniques, the system efficiency has been optimized and the operating range expanded. Thanks to the adjustable blades, this fan is widely applicable within utility and industrial ventilation systems.
Optimized Design for Smoke and Heat Extraction
With its lightweight and robust design, the fan is easy to install and handle. The built-in IEC standard motor is suitable for frequency control, allowing for flexible and energy-efficient operation. The aerodynamically shaped blades ensure high airflow and improved efficiency. The AL 800 D4 F3 06 CFG is certified for smoke gas extraction at temperatures up to 300 °C (F300) and is suitable for continuous operation up to 60 °C. This makes it extremely suitable for dual-use applications in smoke and heat extraction systems as well as standard ventilation. It is supplied without a terminal box, but with a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a renowned German manufacturer of high-quality ventilation solutions. All products are developed with a strong focus on innovation, energy efficiency, and reliability. They comply with current ERP guidelines and perform consistently, even under harsh conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321770 |
| Manufacturer's item number | AL 800 D4 F3 06 CFG |
| Article number | 65170636 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 56430 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
