Good points
- Brand: Ruck
- AC motor
- Standard temperature
- Frequency controlled
Axial 800 mm Duct Fan – AL 800 D84U 03 CFG
The AL 800 D84U 03 CFG from Ruck is an innovative and highly efficient axial fan, specifically designed for medium pressure applications. By utilizing advanced numerical design methods, system efficiency has been improved and the operating range has been expanded. The adjustable blades ensure broad applicability in both commercial and industrial ventilation projects.
Optimized Design with Energy-Efficient 2-Stage Control
This fan features a lightweight and robust design, simplifying installation and maintenance. The IE3 motor is 2-stage controllable via a Dahlander connection, allowing for flexible and efficient operation. The aerodynamically shaped blades contribute to high airflow and increased efficiency. The AL 800 D84U 03 CFG is suitable for continuous operation at medium temperatures up to 60 °C, making it ideal for standard ventilation applications in various environments. It is supplied without a terminal box but includes a cable for connecting an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of ventilation systems. All products are developed with a strong focus on energy efficiency, reliability, and innovation, complying with current ERP guidelines. Ruck guarantees sustainable performance, even under demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544322364 |
| Manufacturer's item number | AL 800 D84U 03 CFG |
| Article number | 65171049 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 55640 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
