Axial 800 mm Duct Fan – AL 800 D4 02 CFG
The AL 800 D4 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. Thanks to the use of advanced numerical design techniques, system efficiency has been enhanced and the operating range expanded. The adjustable blades make this fan versatile for use in both commercial and industrial applications.
Optimized Design for Flexible Ventilation
This fan is designed with a lightweight, robust construction for easy installation and handling. The integrated IEC standard motor is suitable for frequency control, ensuring flexible and energy-efficient operation. The aerodynamically shaped blades provide high airflow and increased efficiency. The AL 800 D4 02 CFG is suitable for continuous operation at air temperatures up to 60 °C, making it ideal for general ventilation applications in various environments. It is supplied without a terminal box, but with a cable for easy connection of an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of axial fans and ventilation solutions. With a strong focus on innovation, energy efficiency, and sustainability, all products comply with current ERP guidelines and deliver reliable performance in a wide range of applications.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Axial duct fan |
| GTIN | 8719544321152 |
| Manufacturer's item number | AL 800 D4 02 CFG |
| Article number | 65170199 |
Specifications
| Category code | 35 |
| Length | 648 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IP55 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 41280 m³/h |
| Suitable for frequency control | Yes |
| Suitable for transformer control | Yes |
| Suitable for electronic control | No |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 800 mm |
