Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 710 mm Duct Fan Flue Gas F400 – AL 710 D6 F4 02 CFG
The AL 710 D6 F4 02 CFG from Ruck is an innovative and highly efficient axial fan, specifically designed for flue gas extraction and daily ventilation. Thanks to the use of advanced numerical calculation methods, the design has been optimized for maximum system efficiency. With adjustable blade positions, this model offers a wide operating range, making it suitable for various applications. This fan is F400 certified and suitable for continuous operation up to 60 °C. Thus, it is a reliable dual-use solution: for normal air exchange and flue gas heat extraction in case of fire.
Robust Design with Optimized Weight
The AL 710 D6 F4 02 CFG is designed with a strong yet lightweight construction that ensures easy installation and maintenance. The optimized design results in a lower weight without compromising performance or durability. The fan is equipped with an IE3 motor that can be controlled in two speed stages via a Dahlander connection. This allows for flexible, energy-efficient operation. Thanks to aerodynamically shaped rotor and stator blades, this fan delivers high efficiency in medium pressure applications. This model is particularly suitable for commercial and industrial environments where reliability is essential.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in developing high-quality ventilation solutions. With over 300 employees, the company guarantees innovation, reliability, and safety. The AL 710 D6 F4 02 CFG complies with current ERP guidelines and is designed according to the strictest requirements for fire safety and energy efficiency.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322647 |
| Manufacturer's item number | AL 710 D6 F4 02 CFG |
| Article number | 65171223 |
Specifications
| Category code | 35 |
| Length | 433 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 26640 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 710 mm |
