Good points

Brand: Ruck
AC motor
Rookgas F400
Frequency controlled

Axial 710 mm Duct Fan Flue Gas F400 – AL 710 D6 F4 01 CFG

The AL 710 D6 F4 01 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. By utilizing the latest numerical design techniques, the operating range has been expanded and system efficiency optimized. Thanks to adjustable blade angles, this fan is widely applicable within HVAC and industrial ventilation systems.

Optimized Design for Flue Gas and Heat Extraction

This fan is designed with a lightweight, robust housing for easy installation and handling. The integrated IEC standard motor is suitable for frequency control, allowing you to adjust the fan energy-efficiently to the desired air volume. The aerodynamically shaped blades ensure a powerful airflow and high efficiency. The AL 710 D6 F4 01 CFG is certified for flue gas extraction up to 400 °C (F400) and suitable for continuous operation up to 60 °C – ideal for dual-use applications such as daily ventilation and flue gas and heat extraction during a fire. Delivered without a terminal box, with connection cable for external switching.

Reliable Quality from Ruck

Ruck Ventilatoren GmbH is a renowned German manufacturer known for innovative ventilation solutions. With a strong focus on energy efficiency and reliable performance, all products comply with current ERP guidelines. Ruck guarantees long-lasting and stable operation under demanding conditions.

More Information

Brand	Ruck ventilatoren GmbH
Category	Flue Gas Axial Fan
GTIN	8719544321664
Manufacturer's item number	AL 710 D6 F4 01 CFG
Article number	65170527

Specifications

Category code	35
Length	433 mm
Connection	Insert end
Housing material	Steel
Electrical connection	Terminals
Degree of protection (IP)	IPX4
Connection voltage	400 V
With thermal overload protection	Yes
Indirect drive	No
Air volume, unloaded	23750 m³/h
Suitable for frequency control	Yes
Pole-reversible	No
Suitable for transformer control	No
Suitable for electronic control	Yes
Max. air temperature	60 °C
Suitable for low-current control	No
Direct-current motor	No
2-speed motor	No
Duct diameter	710 mm
