Good points
- Brand: Ruck
- AC motor
- Rookgas F400
- Frequency controlled
Axial 710 mm Duct Fan Flue Gas F400 – AL 710 D4 F4 01 CFG
The AL 710 D4 F4 01 CFG from Ruck is an innovative and highly efficient axial fan, designed for medium pressure applications. Thanks to the use of advanced numerical simulation techniques, system efficiency has been improved and the operating range has been expanded. The adjustable blades ensure a wide range of applications in both commercial buildings and industrial ventilation systems.
Optimized Design for Flue Gas and Heat Extraction
The lightweight, robust design of this fan allows for easy handling and installation. The fan is equipped with an IEC standard motor that can be controlled via a frequency inverter, providing flexibility and energy savings. With aerodynamically optimized blades, this model delivers high airflow and increased efficiency. The AL 710 D4 F4 01 CFG is suitable for continuous operation up to 60 °C and is certified for flue gas extraction in case of fire up to 400 °C (F400). This makes it ideal for both daily ventilation and use in flue gas and heat extraction systems (dual-use). It is supplied without a terminal box, with a cable for easy connection of an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a leading manufacturer from Germany, specializing in high-quality axial fans. With a strong focus on energy efficiency and innovation, all products comply with current ERP guidelines and provide reliable performance even under the most demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321633 |
| Manufacturer's item number | AL 710 D4 F4 01 CFG |
| Article number | 65170518 |
Specifications
| Category code | 35 |
| Length | 433 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 36900 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 710 mm |
