Axial 710 mm Duct Fan Flue Gas F300 – AL 710 D4 F3 02 CFG
The AL 710 D4 F3 02 CFG from Ruck is an innovative, high-efficiency axial fan designed for medium pressure applications. Thanks to the use of advanced numerical simulation techniques, the system efficiency has been optimized and the operating range significantly expanded. The adjustable blade angles make the fan versatile for use in both commercial projects and industrial installations.
Optimized Design for Flue Gas Exhaust and Standard Ventilation
This fan features a lightweight and robust construction, simplifying installation and maintenance. The integrated IEC standard motor is suitable for frequency control, allowing for flexible and energy-efficient operation. The aerodynamically shaped blades achieve a high airflow with improved efficiency. The fan is certified for flue gas exhaust in case of fire (F300) and is also suitable for continuous operation up to 60 °C – ideal for dual-use applications in HVAC environments. It is supplied without a terminal box, with a connection cable for an external switch.
Reliable Quality from Ruck
Ruck Ventilatoren GmbH is a renowned German manufacturer of axial fans. With years of expertise in ventilation technology, innovative approaches, and a strong focus on energy efficiency, they provide high-quality solutions that meet the latest ERP guidelines. Ruck guarantees sustainable performance in critical and demanding applications.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321602 |
| Manufacturer's item number | AL 710 D4 F3 02 CFG |
| Article number | 65170508 |
Specifications
| Category code | 35 |
| Length | 433 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 29750 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 710 mm |
