Good points
- Brand: Ruck
- AC motor
- Rookgas F300
- Frequency controlled
Axial 630 mm Duct Fan Flue Gas F300 – AL 630 D84U F3 01 CFG
The AL 630 D84U F3 01 CFG from Ruck is an innovative and energy-efficient axial fan, designed for flue gas extraction and daily ventilation. By applying the latest numerical methods, the design has been optimized for high system efficiency. Thanks to adjustable blade angles, this fan has a wide operating range and is suitable for various applications. The model is F300 certified and suitable for continuous use up to 60 °C. This makes it an ideal dual-use solution: applicable for both air exchange and smoke heat extraction in case of fire.
Robust Design with Optimized Weight
The AL 630 D84U F3 01 CFG features a sturdy yet lightweight construction that simplifies installation and maintenance. The optimized product design ensures reduced weight without compromising performance or durability. The fan is equipped with an IE3 motor with two-speed control via a Dahlander connection, allowing for flexible and energy-efficient switching between different power levels. The aerodynamically shaped rotor and stator blades deliver high efficiency, even in medium-pressure applications. Due to its size, this model is ideal for use in medium-sized industrial and commercial installations.
Quality Guaranteed
Ruck Ventilatoren GmbH is a leading German manufacturer with years of experience in ventilation technology. With over 300 employees, they develop high-quality fans that meet the strictest standards in fire safety and energy efficiency. The AL 630 D84U F3 01 CFG also complies with current ERP guidelines and is built for reliable performance in demanding conditions.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544322500 |
| Manufacturer's item number | AL 630 D84U F3 01 CFG |
| Article number | 65171160 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 25630 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 630 mm |
