Axial 630 mm Duct Fan Flue Gas F300 – AL 630 D6 F3 02 CFG
The AL 630 D6 F3 02 CFG from Ruck is an innovative, high-efficiency axial fan, specifically designed for medium pressure applications and flue gas extraction in accordance with the F300 standard. Thanks to the application of the latest numerical design techniques, system efficiency has been enhanced and the operating range has been expanded. The adjustable blades make this fan versatile for both regular ventilation and smoke and heat extraction during a fire (dual-use).
Optimized Design for Flexible Performance
This fan features a lightweight, robust design that facilitates installation and handling. Equipped with an IEC standard motor suitable for frequency control, you can flexibly adjust the fan to meet your specific requirements. The aerodynamically optimized blades ensure efficient airflow and improved performance. This model is suitable for continuous operation at air temperatures up to 60 °C and fully complies with the F300 standard for flue gas ventilation. Delivered without a terminal box, but with a cable for easy connection to an external switch.
Reliable Performance from Ruck
Ruck Ventilatoren GmbH is a leading German manufacturer of axial fans. With years of experience in ventilation technology, Ruck delivers reliable and energy-efficient products that comply with the latest ERP (Energy Related Product) guidelines. These fans provide high performance and durability in the most demanding applications.
More Information
| Brand | Ruck ventilatoren GmbH |
| Category | Flue Gas Axial Fan |
| GTIN | 8719544321572 |
| Manufacturer's item number | AL 630 D6 F3 02 CFG |
| Article number | 65170483 |
Specifications
| Category code | 35 |
| Length | 443 mm |
| Connection | Insert end |
| Housing material | Steel |
| Electrical connection | Terminals |
| Degree of protection (IP) | IPX4 |
| Connection voltage | 400 V |
| With thermal overload protection | Yes |
| Indirect drive | No |
| Air volume, unloaded | 18610 m³/h |
| Suitable for frequency control | Yes |
| Pole-reversible | No |
| Suitable for transformer control | No |
| Suitable for electronic control | Yes |
| Max. air temperature | 60 °C |
| Suitable for low-current control | No |
| Direct-current motor | No |
| 2-speed motor | No |
| Duct diameter | 630 mm |
